Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Bently Nevada 128085-01 |
| Product ID | 128085-01 |
| Manufacturer | Bently Nevada |
| Product Type | Keyphasor® I/O Module |
| Series | 3500 Machinery Protection System |
| Function | Provides shaft rotational speed and phase reference signals for machinery monitoring and protection |
| Module Type | Keyphasor® I/O Module |
| Input Channels | 2 Independent Keyphasor Channels |
| Input Signal Type | Proximity Probe or Magnetic Pickup Signals |
| Input Voltage Range | −24 VDC to +24 VDC |
| Trigger Type | User-configurable threshold crossing |
| Speed Measurement Range | 0.0167 Hz to 20 kHz (1 rpm to 1,200,000 rpm equivalent) |
| Signal Conditioning | Internal filtering and pulse shaping |
| Output Function | Phase Reference, Speed Reference, Trigger Signal Distribution |
| Rack Interface | 3500 Rack Backplane |
| Power Supply | Supplied through 3500 Rack |
| LED Indicators | OK, TX/RX, Channel Status |
| Communication | Compatible with 3500 Rack and System 1® Software |
| Rack Compatibility | Bently Nevada 3500 Machinery Protection System |
| Mounting Type | Rear rack I/O module |
| Operating Temperature | 0°C to +65°C |
| Storage Temperature | −40°C to +85°C |
| Relative Humidity | Up to 95% non-condensing |
| Application | Turbines, compressors, generators, motors, pumps, and rotating machinery |
| Dimensions (H × W × D) | Approx. 241 × 24 × 99 mm |
| Weight | Approx. 0.36 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Bently Nevada 128085-01 used for?
It is a Keyphasor® I/O Module that provides accurate shaft speed and phase reference signals for machinery protection and condition monitoring systems.
Q2: What is a Keyphasor signal?
A Keyphasor signal is a once-per-revolution or multiple-per-revolution pulse used as a timing reference for vibration analysis, phase measurements, and speed calculations.
Q3: How many channels does the module support?
The 128085-01 supports two independent Keyphasor input channels.
Q4: Which sensors can be connected to this module?
It accepts signals from proximity probes and magnetic pickup sensors used to detect shaft rotational events.
Q5: Does the module measure speed directly?
Yes. It processes pulse inputs to provide shaft speed and phase reference information for the 3500 monitoring system.
Q6: Is a separate power supply required?
No. The module receives power directly from the 3500 rack backplane.
Q7: Which systems is it compatible with?
It is designed specifically for the Bently Nevada 3500 Machinery Protection System and integrates with System 1® software.
Q8: What should be verified before replacement?
Verify the part number, I/O configuration, sensor type, rack compatibility, and system configuration settings before installation.
