Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Bently Nevada 169825-01 |
| Product ID | 169825-01 |
| Manufacturer | Bently Nevada |
| Product Type | General Purpose Monitor Module |
| Series | 3500 Machinery Protection System |
| Function | Continuous monitoring of machinery vibration and condition parameters |
| Module Format | Half-height rack module |
| Channel Capacity | 4 Channels |
| Input Type | Dynamic vibration and position transducer inputs |
| Supported Measurements | Radial vibration, thrust position, differential expansion, eccentricity, and process variables (configuration dependent) |
| Signal Processing | Digital signal conditioning and monitoring |
| Alarm Functions | User-configurable Alert and Danger alarms |
| Output Interface | Buffered outputs, rack communication, alarm relay interaction |
| Communication | Compatible with 3500 Rack Communication Gateway and System 1 Software |
| Power Supply | Provided through 3500 rack backplane |
| Power Consumption | Approx. 5–8 W |
| LED Indicators | OK, TX/RX, Bypass, Channel Status |
| Rack Compatibility | Bently Nevada 3500 Standard Rack |
| Mounting Type | Front rack insertion module |
| Operating Temperature | 0°C to +65°C |
| Storage Temperature | −40°C to +85°C |
| Relative Humidity | Up to 95% non-condensing |
| Environmental Rating | Industrial machinery monitoring environments |
| Dimensions (H × W × D) | Approx. 241 × 24 × 241 mm |
| Weight | Approx. 0.45 kg |
| Application | Turbines, compressors, pumps, motors, generators, and critical rotating equipment |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Bently Nevada 169825-01 used for?
It is a monitoring module used within the 3500 Machinery Protection System for continuous condition monitoring of rotating equipment.
Q2: How many channels does the module support?
The module supports up to four monitoring channels, depending on the configured application.
Q3: What types of measurements can it process?
It can be configured for vibration, shaft position, thrust position, differential expansion, eccentricity, and other machinery monitoring parameters.
Q4: Does the module provide alarm protection?
Yes. User-configurable Alert and Danger alarm setpoints are available for machinery protection functions.
Q5: Is a separate power supply required?
No. The module receives power directly from the 3500 rack backplane.
Q6: Which systems is it compatible with?
It is designed exclusively for installation in the Bently Nevada 3500 Machinery Protection System.
Q7: Can the module communicate with asset management software?
Yes. It supports communication through compatible 3500 rack interfaces and Bently Nevada System 1 software.
Q8: What should be verified before replacement?
Verify the module part number, rack configuration, firmware compatibility, I/O module requirements, and application configuration before installation.
