Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 21000-00-00-00-035-04-02 |
| Housing Material | Aluminum body with 304 stainless steel sleeve |
| Temperature Range | -51°C to +177°C (operating and storage) |
| Compatible Probes | 3300 XL 8mm, 11mm, NSv |
| Sleeve Length | Varies by installation (up to 742 mm max) |
| Weight (Typical) | 1.1 kg (without fittings) |
| Housing Diameter | 83.3 mm |
| Housing Length | 161.6 mm (excluding probe) |
| Mounting Thread | 3/4-14 NPT standard (other options available) |
| Certification | CSA approved explosion-proof, API 670 compliant |
| Enclosure Rating | Type 4 |
FAQ
Frequently Asked Questions (FAQ) – Q&A Format
Q1: Is this product explosion-proof certified?
A1: Yes, the 21000 housing is CSA certified for use in Class I, II, III hazardous areas.
Q2: Can it be used with 3300 XL NSv probes?
A2: Yes, it supports 3300 XL NSv, 8mm, and 11mm probe types.
Q3: What is the maximum allowable sleeve length for the probe?
A3: The maximum length depends on cable length and can reach up to 742 mm for 1-meter cables.
Q4: Does the housing comply with API 670 standard?
A4: Yes, the 21000 series meets API 670 requirements for external proximity probe housings.
Q5: Are other materials available for this housing?
A5: Yes, the stainless steel version is available as model 24701.
Q6: What if the sleeve length exceeds 12 inches?
A6: For sleeves longer than 304 mm, a sleeve support like part 37948-01 is recommended to avoid resonance.
Q7: What are the allowable environmental temperatures for operation?
A7: It is designed for environments ranging from -51°C to +177°C for both operation and storage.
Q8: Are probe options with connector protectors available?
A8: Yes, variants with connector protectors are supported, such as options A:31, A:33, and A:35.
