Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 31000-16-05-00-100-03-02 |
| Probe Type | 3300 XL 8 mm |
| Probe Cable Length | 0.5 meter |
| Operating Temperature | -51°C to +177°C |
| Storage Temperature | -51°C to +177°C |
| Housing Material | Glass-reinforced Polyphenylene Sulfide (PPS) with conductive fibers |
| Sleeve & Retaining Chain | AISI 304 stainless steel |
| Exterior Screws & Outer Sleeve | AISI 303 stainless steel |
| O-Ring Material | Neoprene |
| Ingress Protection Rating | NEMA 4X / IP66 |
| Protection Certifications | CSA Type 4X, CENELEC EN50014 (electrostatic dissipation) |
| Housing Impact Resistance | 7 Joules at ambient (CSA), 4 Joules at -39°C and 115°C (BASEEFA) |
| Recommended Torque | 29.4 N·m (260 in·lb) for retaining nut |
| Maximum Probe Penetration | 10.0 in (254 mm) — based on Option D: 100 |
| Mounting Thread Option | 3/4-14 NPT |
| Fittings | One 3/4-14 NPT + accessories (Option 03) |
| Weight | 1.2 kg (2.6 lb) |
FAQ
FAQ
Q1: What type of probe is used in the 31000-16-05-00-100-03-02 housing?
A1: This model uses the 3300 XL 8 mm proximity probe.
Q2: What is the probe cable length for this specific model?
A2: The probe cable length is 0.5 meters.
Q3: What environmental conditions can the housing withstand?
A3: The housing supports operating and storage temperatures from -51°C to +177°C.
Q4: What materials are used in the construction of the housing?
A4: The housing is made from glass-reinforced PPS thermoplastic with stainless steel components.
Q5: Does the housing provide ingress protection?
A5: Yes, it is rated NEMA 4X and IP66, suitable for hose-directed water and dust-tight environments.
Q6: Is this housing explosion-proof?
A6: No, this model is not explosion-proof. For explosion-proof needs, use CA21000 or CA24701.
Q7: Can this housing be used in hazardous areas?
A7: Yes, when paired with an approved transducer system and I.S. barriers, it can be used in intrinsically safe areas.
Q8: What is the weight of this proximity probe housing?
A8: The housing weighs approximately 1.2 kg (2.6 lb).
