Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | 31000-16-05-15-100-03-02 |
| Probe Type | 3300 XL 8 mm |
| Probe Cable Length | 0.5 meter |
| Operating Temperature | -51°C to +177°C (-60°F to +351°F) |
| Storage Temperature | -51°C to +177°C (-60°F to +351°F) |
| Housing Material | Glass-reinforced Polyphenylene Sulfide (PPS) with conductive fibers |
| Sleeve & Retaining Chain Material | AISI 304 stainless steel |
| Outer Sleeve & Screws Material | AISI 303 stainless steel |
| O-Ring Material | Neoprene |
| Protection Rating | NEMA 4X / IP66 |
| Mechanical Impact Strength | 7 Joule @ room temp (CSA verified), 4 Joule @ -39°C and 115°C (BASEEFA) |
| Housing Strength (typical) | Supports 912 N (205 lb) at 38 mm from end |
| Recommended Torque | 29.4 N·m (260 in·lb) for retaining nut |
| Mounting Thread Option | 3/4-14 NPT |
| Standoff Adapter Length | 1.5 inches (38 mm) |
| Probe Penetration Length | 3.9 inches (100 mm) |
| Weight | 1.2 kg (2.6 lb) |
FAQ
FAQ
Q1: What type of probe does the 31000-16-05-15-100-03-02 housing support?
A1: It supports the 3300 XL 8 mm proximity probe.
Q2: What is the length of the probe cable for this model?
A2: The probe cable length is 0.5 meter.
Q3: What is the operating temperature range of this housing?
A3: The operating range is from -51°C to +177°C (-60°F to +351°F).
Q4: What material is the housing made from?
A4: The housing is made from glass-reinforced PPS thermoplastic with conductive fibers.
Q5: Is this housing suitable for hazardous areas?
A5: Yes, it complies with API 670 and is usable in intrinsically safe hazardous areas when installed properly.
Q6: What protection ratings does the housing meet?
A6: It meets NEMA 4X and IP66 standards for water and dust ingress protection.
Q7: What is the recommended torque for installing the retaining nut?
A7: The recommended torque is 29.4 N·m (260 in·lb).
Q8: What is the weight of the 31000-16-05-15-100-03-02 assembly?
A8: The typical weight is 1.2 kg (2.6 lb).
