Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Bently Nevada 330100-50-01 |
| Product ID | 330100-50-01 |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Series | 3300 XL Proximitor® Transducer System |
| Function | Non-contact measurement of shaft vibration, position, eccentricity, and displacement in rotating machinery |
| Measurement Technology | Eddy Current Proximity Sensing |
| Probe Diameter | 8 mm |
| Thread Type | 3/8-24 UNF |
| Unthreaded Length | 0 mm (Option 00) |
| Case Length | 5.0 in (127 mm) (Option 50) |
| Connector Type | Standard Miniature Coaxial Connector (Option 01) |
| Probe Material | Stainless Steel Housing |
| Probe Tip Material | PPS (Polyphenylene Sulfide) |
| Sensitivity | 7.87 V/mm (200 mV/mil) Typical |
| Frequency Response | 0 Hz to 10 kHz |
| Operating Temperature | −51°C to +177°C |
| System Compatibility | Bently Nevada 3300 XL 8 mm Proximitor® Sensors and Extension Cables |
| Application | Steam Turbines, Gas Turbines, Compressors, Pumps, Motors, Generators |
| Dimensions & Weight | Probe diameter 8 mm, case length 127 mm, overall probe length approximately 160 mm, weight approximately 0.10–0.15 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Bently Nevada 330100-50-01 used for?
It is an 8 mm proximity probe used for non-contact measurement of shaft vibration and position in rotating machinery.
Q2: What does option 50 indicate?
Option 50 specifies a probe case length of 5.0 inches (127 mm).
Q3: What does option 01 indicate?
Option 01 specifies the standard miniature coaxial connector configuration.
Q4: What monitoring applications is this probe suitable for?
It is commonly used for shaft vibration, thrust position, differential expansion, and rotor eccentricity monitoring.
Q5: What are the dimensions and weight?
The probe has an 8 mm diameter, a 127 mm case length, an overall length of approximately 160 mm, and weighs approximately 0.10–0.15 kg.
Q6: Is this probe compatible with all Proximitor® sensors?
No. It is designed specifically for use with compatible Bently Nevada 3300 XL 8 mm Proximitor® sensor systems.
Q7: What material is the probe made from?
The housing is stainless steel with a PPS probe tip for durability and environmental resistance.
Q8: What should be verified before replacement?
Verify probe diameter, case length, connector type, extension cable configuration, and compatibility with the existing 3300 XL transducer system.
