Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Bently Nevada 330101-30-63-10-02-05 |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Total Length | 1.0 meter |
| Weight | 0.323 kg |
| Probe Tip Diameter | 8.0 mm |
| Probe Case Material | AISI 303/304 Stainless Steel |
| Probe Cable Type | 75Ω triaxial FEP insulated |
| Recommended Gap Setting | 1.27 mm (50 mils) |
| Linear Range | 2 mm (80 mils) |
| Frequency Response | 0 to 10 kHz (+0, -3 dB) |
| Operating Temperature | -52°C to +177°C (Standard Probe) |
| Storage Temperature | -52°C to +177°C |
| Minimum Target Size | 15.2 mm diameter (flat) |
| Shaft Diameter (min/recommended) | 50.8 mm / 76.2 mm |
| Connector Type | Miniature coaxial ClickLoc |
| Tensile Strength | 330 N (probe case to lead), 270 N (lead to extension) |
| Humidity Tolerance | <3% change at 93% RH over 56 days |
| Compliance | FCC Part 15, CE, RoHS, SIL 2/3 |
FAQ
FAQ
Q1: What is the recommended gap setting for this probe?
A1: The recommended gap setting is 1.27 mm (50 mils).
Q2: What is the operating temperature range of the probe?
A2: The standard probe operates from -52°C to +177°C.
Q3: What is the linear range of the 330101 probe?
A3: The linear range is 2 mm (80 mils).
Q4: What is the frequency response of the probe?
A4: The frequency response is 0 to 10 kHz (+0, -3 dB).
Q5: What is the minimum shaft diameter this probe can be used with?
A5: The minimum shaft diameter is 50.8 mm, with 76.2 mm recommended.
Q6: What are the length and weight of the probe?
A6: The total length is 1.0 meter, and the weight is 0.323 kg.
Q7: Are special tools required to install the ClickLoc connector?
A7: No, the ClickLoc connector is designed to be tightened by hand.
Q8: Does the probe comply with international certification standards?
A8: Yes, the probe meets FCC, CE, RoHS standards and supports SIL 2/3 safety levels.
