Technical Specifications
| Parameter | Description |
|---|---|
| Manufacturer | Bently Nevada |
| Product | **** (Representative 3300 series 5 mm proximity probe — 330174‑00‑08‑50‑02‑05 variant follows same family design) |
| Product Model | 330174‑00‑08‑50‑02‑05 |
| Product Type | 3300 Series 5 mm Eddy‑Current Proximity Probe |
| Measurement Principle | Non‑contact eddy‑current displacement & vibration sensing |
| Probe Tip Diameter | 5 mm (standard) |
| Thread Size | M8 × 1 threaded mount |
| Unthreaded Length | 0 mm (code “00”) |
| Overall Rigid Body Length | 80 mm (code “08”) |
| Cable Length | 5.0 m (code “50”) (~16.4 ft) |
| Connector Type | Miniature coaxial ClickLoc™ connector (code “02”) |
| Agency Approval | CSA, ATEX, IECEx approvals (code “05”) |
| Linear Sensing Range | ~0.25 mm – ~2.3 mm typical for 3300 5 mm probes |
| Output Signal | Analog voltage proportional to gap/displacement (conditioning electronics required) |
| Frequency Response | DC to ~10 kHz typical |
| Operating Temperature Range | Approx. –35 °C to +177 °C industrial range |
| Housing Material | Stainless steel rugged industrial body |
| Cable Jacket | FEP‑insulated, shielded coaxial cable |
| Dimensions | Probe body ~80 mm length × 5 mm diameter; cable ~5.0 m |
| Weight | ~0.71 kg assembled |
| Operating Environment | Industrial rotating machinery condition monitoring |
| Compliance | Designed for use with 3300 series proximitor and monitoring electronics |
FAQ
FAQ
Q1: What is the Bently Nevada 330174‑00‑08‑50‑02‑05 used for?
A1: It is a 5 mm eddy‑current proximity probe used for non‑contact measurement of shaft vibration and displacement on industrial rotating machinery as part of a condition monitoring system.
Q2: What do the model number segments “00‑08‑50‑02‑05” mean?
A2: “00” indicates no unthreaded section, “08” is the rigid probe body length (80 mm), “50” denotes a 5.0 m cable, “02” identifies the miniature coaxial ClickLoc™ connector, and “05” indicates agency approvals like CSA, ATEX, and IECEx.
Q3: What is the typical sensing range of this probe?
A3: The probe typically provides a linear sensing range from roughly 0.25 mm up to about 2.3 mm from the target surface, depending on system setup.
Q4: What type of output signal does this probe provide?
A4: It outputs an analog voltage proportional to the gap/displacement, which must be conditioned by a proximitor sensor or monitoring electronics.
Q5: What environments is this probe suitable for?
A5: It is designed for harsh industrial environments and can operate across wide temperature ranges typical in heavy machinery monitoring.
Q6: What connector and cable does this probe use?
A6: It uses a miniature coaxial ClickLoc™ connector with a 5.0 m integral cable, providing reliable connection and installation flexibility.
Q7: Do I need additional components to use this probe?
A7: Yes — you need compatible proximitor conditioning electronics and any necessary extension cables or monitoring hardware to condition and analyze the probe’s raw signal.
Q8: What is the approximate weight of the assembled probe?
A8: The assembled proximity probe with its cable weighs about 0.71 kg.
