Technical Specifications
| Parameter | Description |
|---|---|
| Manufacturer | Bently Nevada 330180‑X0‑00 |
| Product Model | 330180‑X0‑00 (related family: 330180‑XX‑XX proximitor sensors) |
| Product Type | 3300 XL Series Proximitor Sensor |
| Measurement Principle | Non‑contact eddy‑current displacement, vibration, and position measurement |
| Probe Compatibility | Designed for use with 3300 XL 5 mm and 8 mm proximity probes |
| Output Signal | Analog voltage (proportional to gap/displacement) |
| Linear/Measurement Range | Compatible with typical 5 mm probe linear ranges (~0.25 mm–2.0 mm) and 8 mm probe ranges (~0.51 mm–2.29 mm) |
| Operating Voltage | 24 V DC typical |
| Frequency Response | Up to 10 kHz |
| Operating Temperature Range | ~‑35 °C to +100 °C (industrial environments) |
| Mounting Options | Panel mount or DIN rail mount (varies by specific sub‑model) |
| Housing Material | Rugged industrial enclosure |
| Dimensions | Approx. 198 mm × 162 mm × 108 mm (typical proximitor housing) |
| Weight | ~1.35 kg assembled |
| Environmental Protection | Designed for industrial condition monitoring (not necessarily IP67 unless specified) |
| Compliance | Compatible with API 670 machine protection and condition monitoring systems |
FAQ
FAQ
Q1: What is the Bently Nevada 330180‑X0‑00?
A1: It is a 3300 XL Series Proximitor Sensor module used for industrial non‑contact measurement of vibration, displacement, and position with compatible eddy‑current proximity probes.
Q2: What probes can be used with this sensor?
A2: This sensor is compatible with both 3300 XL 5 mm and 8 mm proximity probes, allowing measurement of machinery shaft movement and vibration.
Q3: What signal output does the Proximitor provide?
A3: It generates an analog voltage proportional to the gap/displacement measured by the connected proximity probe; further signal conditioning and monitoring hardware are often used.
Q4: What is the typical operating voltage?
A4: It typically operates from a 24 V DC supply.
Q5: What environments is this sensor suitable for?
A5: It is designed for rugged industrial environments, operating in wide temperature ranges common to rotating machinery condition monitoring.
Q6: How is this proximitor mounted?
A6: It can be panel mounted or DIN rail mounted depending on the specific sub‑model configuration.
Q7: Does this sensor meet any industry standards?
A7: Yes, when properly installed as part of a 3300 XL transducer system, it is suitable for API 670 machine protection and vibration monitoring.
Q8: What additional components are needed to form a complete measurement system?
A8: A proximitor sensor requires compatible 3300 XL proximity probes and, optionally, extension cables and monitoring electronics to condition, record, and interpret the measurements.
