Technical Specifications
| Parameter | Specification |
|---|---|
| Sensitivity | 3.94 mV/mm/s (100 mV/in/s) ±5% |
| Frequency Response | 4.5 Hz to 5 kHz (±3.0 dB), 6.0 Hz to 2.5 kHz (±0.9 dB) |
| Velocity Range | 1270 mm/s (50 in/s) peak |
| Amplitude Linearity | ±2% to 152 mm/s (6 in/s) peak |
| Transverse Sensitivity | <5% |
| Temperature Sensitivity | -14% to +7.5% (typical over full range) |
| Mounted Resonant Frequency | >12 kHz |
| Output Bias Voltage | -12 ±3.0 VDC |
| Dynamic Output Impedance | <2400 Ω |
| Broadband Noise Floor | 0.004 mm/s (160 μin/s) rms |
| Grounding | Case isolated |
| Maximum Cable Length | 305 m (1000 ft), using cable 02173006 |
| Operating Temperature Range | -55°C to +121°C (-67°F to +250°F) |
| Shock Survivability | 5,000 g peak |
| Relative Humidity | 100%, non-submerged; hermetically sealed case |
| Magnetic Field Susceptibility | <51 mm/s/gauss (50 gauss, 50-60 Hz) |
| Base Strain Sensitivity | 0.005 in/s/mstrain |
| Weight | 142 g (0.142 kg / 5.0 oz) |
| Sensor Head Diameter | 25.3 mm (0.995 in) |
| Height | 63.2 mm (2.49 in) |
| Case Material | 316L stainless steel |
| Connector | 2-pin Mil-C-5015, hermetically sealed |
| Mounting Torque | 32–46 kg·cm (24–40 in·lb) |
| Polarity | Motion toward connector makes Pin A positive |
FAQ
FAQ
Q1: What is the primary function of the 330500 Velomitor Piezo-velocity Sensor?
A1: It measures absolute casing or bearing housing vibration for machinery condition monitoring.
Q2: Can the sensor be installed in any orientation?
A2: Yes, it can be mounted vertically, horizontally, or at any angle due to its solid-state design.
Q3: What is the maximum cable length that can be used without signal degradation?
A3: Up to 305 meters (1000 feet) using the specified cable (02173006) without performance loss.
Q4: What environmental conditions can it withstand?
A4: The sensor operates from -55°C to +121°C, with 100% relative humidity, and up to 5000 g shock.
Q5: How is the sensor protected against electromagnetic interference?
A5: It has magnetic field susceptibility of <51 mm/s/gauss at 50 gauss and is case isolated.
Q6: What certifications does the 330500 sensor have?
A6: It complies with FCC, EMC 2014/30/EU, RoHS 2011/65/EU, and various ATEX, CSA, and DNV standards.
Q7: What is the typical output signal of the sensor?
A7: 3.94 mV/mm/s (100 mV/in/s), with a bias voltage of -12 ±3 VDC.
Q8: What is the recommended mounting torque for proper installation?
A8: 32 to 46 kg·cm (24 to 40 in·lb) is recommended for optimal mounting integrity.
