Technical Specifications
| Parameter | Specification |
|---|---|
| Linear Range | 12.7 mm (500 mils) |
| Average Scale Factor (ASF) | 0.787 V/mm (20 mV/mil) |
| Frequency Response | 0 – 2.7 kHz (+0, -3 dB up to 305 m of field wire) |
| Min Target Size | 61 mm (2.4 in) diameter flat target |
| Operating Temp (Sensor) | -51°C to +100°C |
| Operating Temp (Probe) | -35°C to +200°C; up to +250°C short-term (<24h) |
| Operating Temp (Cable) | -35°C to +200°C |
| Humidity | 100% condensing (non-submersible if protected) |
| Bracket Adj. Range | Short: ±25.4 mm; Long: ±76.2 mm |
| Power Supply Required | -17.5 Vdc to -26 Vdc, 12 mA max |
| Cable Capacitance | 69.9 pF/m typical |
| Output Resistance | 50 Ω |
| Total System Length | 9.0 meters (29.5 feet) |
| Weight | 0.255 kg (Proximitor Sensor) |
| Probe Cable Type | FluidLoc PFA insulated triaxial |
| Probe Housing Material | AISI 304 Stainless Steel |
| Sensor Housing Material | A380 Aluminum |
| Probe Tip Material | PEEK (Polyetheretherketone) |
| Min Bend Radius | 25.4 mm (1.0 inch) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the measurement range of the 330850-91-00 sensor?
A1: It offers a linear measurement range of 12.7 mm (500 mils), ideal for differential expansion (DE) in turbines.
Q2: What is the maximum temperature it can withstand?
A2: The probe operates continuously up to +200°C and up to +250°C short-term. The sensor operates from -51°C to +100°C.
Q3: Is it compatible with older 7200 systems?
A3: Yes, it physically replaces all 7200 25 mm/35 mm transducers and retains the same output for easy upgrades.
Q4: What are the power supply requirements?
A4: Requires -17.5 Vdc to -26 Vdc, with a maximum current of 12 mA.
Q5: Must I calibrate with AISI 4140 target material?
A5: Yes, for best accuracy, calibration is factory-tuned for AISI 4140 steel.
Q6: Can this be used in high humidity environments?
A6: Yes, up to 100% condensing humidity, as long as connectors are protected; not fully submersible.
Q7: How is the sensor mounted?
A7: It supports DIN rail and panel mount options, with sliding brackets for alignment.
Q8: What does the 9.0 meter system length refer to?
A8: It includes both the probe and extension cable. The Proximitor Sensor itself weighs 0.255 kg in this configuration.
