Technical Specifications
| Item | Specification |
|---|---|
| Model | Bently Nevada 330851-02-000-070-50-00-CN |
| Series | 3300 XL 25 mm Proximity Probe |
| Probe Type | Non-contacting eddy current proximity probe |
| Measurement Range | 0 to 12.7 mm (0 to 500 mils) |
| Linear Range | 0.25 to 12.7 mm |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Probe Tip Diameter | 25 mm |
| Frequency Response | 0 to 10 kHz |
| Operating Temperature | -35°C to +177°C |
| Storage Temperature | -35°C to +200°C |
| Probe Material | Stainless steel |
| Cable Type | Integral coaxial cable |
| Cable Length | 5.0 m |
| Mounting Thread | M30 × 1.5 |
| Power Supply | -24 V DC nominal |
| Compatible Drivers | 3300 XL Proximitor Sensor (Models 3300 5 mm, 8 mm, 11 mm, 25 mm systems) |
| Dimensions | Total Length : 5.0 meter |
| Weight | 0.23 kg |
FAQ
FAQ
Q1: What type of equipment is this probe mainly used for?
A1: It is designed for large rotating machinery such as turbines, compressors, and generators for shaft vibration, displacement, and thermal expansion monitoring.
Q2: Is it compatible with 3300 series Proximitor sensors?
A2: Yes, it is fully compatible with the 3300 XL Proximitor sensors for accurate signal processing.
Q3: What is the installation method?
A3: It is mounted using an M30 × 1.5 threaded connection, typically fixed to a probe holder or machine housing.
Q4: What is the operating temperature range?
A4: The operating range is -35°C to +177°C, suitable for harsh industrial conditions.
Q5: What is the probe sensitivity?
A5: The sensitivity is 7.87 V/mm (200 mV/mil) for precise displacement measurements.
Q6: What is the cable length of this model?
A6: The cable length is 5 meters, offering flexibility for remote installations.
Q7: Does the probe require a specific mounting orientation?
A7: Yes, it should be installed perpendicular to the shaft surface for optimal measurement accuracy.
Q8: Is there an explosion-proof version available?
A8: Yes, explosion-proof variants are available for use in flammable or hazardous environments.
