Technical Specifications
| Item | Description |
|---|---|
| Product Model | Bently Nevada 330910-00-03-10-02-00 |
| Product Type | 3300 NSv Proximity Probe |
| Application | Shaft vibration and displacement monitoring in small, high-speed fluid-film bearing machines |
| Probe Tip Diameter | 5 mm (NSv series) |
| Probe Length | 30 mm |
| Cable Length | 1.0 m |
| Connector Type | Miniature coaxial connector, reverse thread |
| Compatible Proximitor | 3300 NSv Proximitor Sensor |
| Linear Range | 2 mm (80 mils) |
| Sensitivity | –7.87 V/mm (–200 mV/mil) |
| System Accuracy | ±5% typical over full linear range |
| Frequency Response | 0 to 8 kHz (–3 dB) |
| Gap Voltage | –1 VDC to –14 VDC |
| Operating Temperature | –35 °C to +177 °C (probe) |
| Storage Temperature | –40 °C to +177 °C |
| Pressure Rating | Up to 10,000 psi (68.9 MPa) with appropriate housing |
| Housing Material | Stainless steel |
| Environmental Protection | IP65 (with proper installation) |
| Dimensions | Total Length : 1.0 meter |
| Weight | 0.15 kg |
FAQ
FAQ
Q1: What is the main application of the 330910-00-03-10-02-00 probe?
It is mainly used for monitoring shaft vibration and displacement in compact high-speed machines, particularly with fluid-film bearings.
Q2: What is the probe tip diameter?
The probe has a 5 mm diameter, ideal for installations with limited space.
Q3: What is the probe length of this model?
This version has a 30 mm probe length.
Q4: Which proximitor is compatible with this probe?
It is designed to operate with the Bently Nevada 3300 NSv Proximitor Sensor.
Q5: What is the linear measurement range?
The linear range is 2 mm (80 mils).
Q6: What is the probe sensitivity?
The probe has a sensitivity of –200 mV/mil (–7.87 V/mm).
Q7: What is the operating temperature range?
It can operate between –35 °C and +177 °C.
Q8: Can it withstand high-pressure environments?
Yes, with the appropriate housing, it can handle pressures up to 10,000 psi (68.9 MPa).
