Technical Specifications
| Item | Specification |
|---|---|
| Model Number | 3500/22-01-01-00 |
| Product Name | Transient Data Interface (TDI) Module |
| System Compatibility | Bently Nevada 3500 Series |
| Function | Combines communication gateway and transient data capture |
| Communication Interface | Ethernet 100Base-TX |
| Supported Protocols | Modbus TCP/IP, BNBus, System 1 |
| Power Requirement | Powered through rack backplane |
| Channel Count | Single channel |
| Slot Position | Occupies Slot 1 and Slot 2 in the rack |
| Configuration | Via 3500 Rack Configuration Software |
| Data Sampling | Real-time vibration and process transient data |
| Operating Temp. | 0°C to +65°C |
| Storage Temp. | -40°C to +85°C |
| Relative Humidity | 95% non-condensing |
| Mounting Method | Mounted in 3500 rack |
| Dimensions | 241.3 x 24.4 x 241.8 mm |
| Weight | 0.91 kg |
FAQ
FAQ
Q1: What is the main function of the 3500/22-01-01-00 module?
A1: It enables transient data acquisition and serves as the communication gateway for the 3500 system.
Q2: Does it need to be installed in a specific rack slot?
A2: Yes, it must be installed in Slots 1 and 2 of the 3500 rack.
Q3: Is redundancy supported with this module?
A3: Yes, redundant configurations with two TDI modules are supported.
Q4: How is the module configured?
A4: Configuration is done using the 3500 Rack Configuration Software.
Q5: Does it have its own power supply?
A5: No, it receives power from the rack backplane.
Q6: What protocols are supported?
A6: It supports Modbus TCP/IP, BNBus, and System 1.
Q7: Can it perform real-time data acquisition?
A7: Yes, it supports high-resolution transient signal sampling for dynamic analysis.
Q8: Are special tools needed for installation?
A8: No, it supports hot-plugging and can be installed directly into the rack.
