Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 3500/40M-01-00 (P/N 176449-01) |
| Manufacturer | Bently Nevada |
| Series | 3500 Machinery Protection System |
| Product Type | Proximitor Monitor |
| Function | Monitors radial vibration, thrust position, differential expansion, eccentricity, and REBAM measurements |
| Channel Count | 4 Channels |
| Input Type | Bently Nevada Proximity Transducers |
| Measurement Functions | Radial Vibration, Eccentricity, REBAM, Thrust Position, Differential Expansion |
| Configuration | 3500 Rack Configuration Software |
| I/O Module Type | 01 – Proximitor I/O Module with Internal Termination |
| Hazardous Area Approval | 00 – None |
| Rack Requirement | 1 Full-Height Front Slot + 1 Full-Height Rear I/O Slot |
| Power Consumption | 7.7 W Typical |
| Communication | Through 3500 Rack and TDI Modules |
| Operating Temperature | -30°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (H × W × D) | 241.3 × 24.4 × 241.8 mm |
| Weight | 0.91 kg |
FAQ
FAQ
Q1: What is 3500/40M-01-00 (176449-01) used for?
It is used for continuous machinery protection and vibration monitoring.
Q2: How many channels does it support?
It supports 4 independent monitoring channels.
Q3: What measurements can it perform?
Radial vibration, eccentricity, REBAM, thrust position, and differential expansion.
Q4: What does the “-01-00” configuration mean?
“01” indicates an internal termination I/O module, and “00” indicates no hazardous-area approval option.
Q5: Which sensors are compatible?
Bently Nevada proximity transducer systems such as 3300 XL and related Proximitor sensors.
Q6: What are its dimensions?
Approximately 241.3 × 24.4 × 241.8 mm.
Q7: What is its weight?
Approximately 0.91 kg.
Q8: In which system is it installed?
It is installed in a Bently Nevada 3500 Machinery Protection System rack.
