Technical Specifications
| Item | Specification |
|---|---|
| Model | 990-10-XX-01-05 / 163930-01 |
| Type | Discrete Output Module (990 Series) |
| Product Category | PLC Output Module |
| Product Family | Modicon 990 Series automation I/O |
| Function | Provides discrete DC output channels for industrial control |
| Number of Output Channels | 10 outputs (configurable “XX” defines exact count) |
| Output Voltage Range | 24 V DC nominal |
| Output Logic | Positive logic (sourcing) |
| Maximum Load Current | 0.5 A per channel (typical) |
| Total Load Current | Depends on module configuration (aggregate limit) |
| Status Indication | Individual LED per output channel |
| Output Protection | Short-circuit and overload protection |
| Mounting Method | DIN rail or 990 base mounting |
| Field Wiring Connection | Screw terminal or spring-clamp terminals |
| Operating Temperature Range | 0 °C to +60 °C |
| Storage Temperature Range | –20 °C to +70 °C |
| Protection Rating | IP20 |
| Housing Material | Industrial-grade plastic |
| Application Environment | Industrial automation and control cabinets |
| Compatibility | Modicon 990 Series PLC racks and base modules |
| Dimensions | Approx. 90 mm × 45 mm × 60 mm |
| Weight | Approximately 0.20 kg |
FAQ
FAQ
Q1: What is the primary purpose of the 990-10-XX-01-05 / 163930-01 module?
It provides multiple discrete DC outputs for switching and controlling field devices such as relays, contactors, lamps, and alarms in an industrial automation system.
Q2: What does the “10-XX-01-05” in the model number signify?
It denotes a 10-point discrete output module with specific connector and approval options; “XX” represents a placeholder for exact channel count or configuration variation.
Q3: What output voltage range does this module support?
The module is designed for a nominal 24 V DC output voltage, common in PLC discrete outputs.
Q4: What is the maximum current per output channel?
Each output channel is typically rated for up to 0.5 A of load current.
Q5: How are outputs connected to field devices?
Outputs are connected using screw terminal or spring-clamp terminals for secure field wiring.
Q6: Does this module provide status indication?
Yes, it includes individual LED indicators for each output channel, showing whether the channel is ON or OFF.
Q7: Can this module be used in harsh industrial environments?
Yes, it is designed for installation in industrial control cabinets under standard operating conditions.
Q8: What are the physical dimensions and weight of the module?
The output module measures approximately 90 mm × 45 mm × 60 mm and weighs around 0.20 kg.
