Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 991-25-70-01-IN |
| Series | Bently Nevada 991 Thrust Sensor |
| Function | Detects axial thrust displacement in rotating machinery to ensure operational stability and bearing protection |
| Sensing Principle | Eddy current induction |
| Measurement Range | 0 to 2 mm (typical) |
| Linearity Error | ≤ ±1% of full scale |
| Sensitivity | 7.87 mV/µm (typical) |
| Operating Temperature | -35°C to +180°C |
| Housing Material | Stainless steel |
| Output Signal | Voltage output proportional to displacement |
| Mounting Method | Threaded installation |
| Dimensions | 100.1 x 73.9 x 53.3 mm |
| Weight | 0.43 kg |
FAQ
FAQ
Q1: What is the main application of the 991-25-70-01-IN thrust sensor?
A: It is primarily used to monitor axial thrust in rotating machinery such as turbines and compressors to prevent mechanical damage.
Q2: What sensing principle does it use?
A: It operates on the eddy current induction principle, measuring displacement in a non-contact manner.
Q3: What is the typical measurement range?
A: The typical measurement range is 0 to 2 mm.
Q4: What type of output signal does it provide?
A: It provides a voltage signal proportional to shaft displacement.
Q5: What is the housing material?
A: Constructed from corrosion-resistant stainless steel for industrial environments.
Q6: What is the operating temperature range?
A: It operates reliably from -35°C to +180°C.
Q7: How is the sensor installed?
A: Installed using a threaded mount for easy positioning and adjustment.
Q8: What are the dimensions and weight?
A: Dimensions are 100.1 x 73.9 x 53.3 mm, and the weight is approximately 0.43 kg.
