Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Emerson Control Techniques (Now Nidec Control Techniques) |
| Product Model | DST1404 |
| Product Type | Servo Drive |
| Series | Digitax ST |
| Function | High-performance AC servo drive for precision motion control |
| Input Voltage | 380–480 VAC, 3-Phase |
| Rated Voltage | 400 VAC |
| Input Frequency | 48–65 Hz |
| Rated Input Phases | 3 |
| Continuous Output Current | 5.9 A RMS |
| Peak Output Current | 17.7 A RMS |
| Rated Power | Approx. 3.0 kW (application dependent) |
| Control Modes | Position Control, Velocity Control, Torque Control |
| Servo Feedback | Incremental Encoder, Absolute Encoder, Resolver, Sine/Cosine Encoder |
| Communication Options | RS-485 (Modbus RTU) standard; optional EtherCAT, EtherNet/IP, PROFINET, PROFIBUS-DP, CANopen, DeviceNet, SERCOS, CTNet, CTSync |
| Safety Function | Safe Torque Off (STO) |
| Protection Rating | IP20 |
| EMC Filter | Integrated |
| Cooling Method | Forced Air Cooling |
| Mounting Type | Panel Mount |
| Operating Temperature | 0°C to +50°C |
| Application | CNC machines, robotics, packaging equipment, printing machinery, textile machinery, semiconductor equipment, and automated production systems |
| Dimensions (W × H × D) | 62 × 322 × 226 mm |
| Weight | 2.1 kg |
| Condition | New and original |
| Warranty | 12 months |
FAQ
FAQ
Q1: What is the Emerson DST1404 used for?
The DST1404 is used to drive AC servo motors in applications requiring accurate position, speed, and torque control, including CNC machinery, robotics, packaging equipment, printing presses, and automated production lines.
Q2: What type of product is the DST1404?
The DST1404 is a Digitax ST intelligent servo drive for high-performance motion control applications requiring fast response and precise servo positioning.
Q3: What are the electrical ratings of the DST1404?
The drive operates on a 380–480 VAC three-phase input, provides 5.9 A continuous output current, and 17.7 A peak output current, making it suitable for medium-power servo motor applications.
Q4: What are the dimensions and weight of the DST1404?
The drive measures approximately 62 × 322 × 226 mm and weighs approximately 2.1 kg (without keypad or optional modules).
Q5: Which feedback devices are supported by the DST1404?
The DST1404 supports incremental encoders, absolute encoders, resolvers, and sine/cosine encoders, allowing compatibility with a wide variety of industrial servo motors.
Q6: Which communication protocols are available?
The drive includes RS-485 with Modbus RTU as standard and supports optional communication modules for EtherCAT, EtherNet/IP, PROFINET, PROFIBUS-DP, CANopen, DeviceNet, and SERCOS.
Q7: Does the DST1404 include safety features?
Yes. The DST1404 includes an integrated Safe Torque Off (STO) function compliant with IEC 61800-5-2, helping improve machine safety while reducing external safety hardware requirements.
Q8: What are the advantages of the Emerson DST1404?
The DST1404 offers high peak torque capability, compact dimensions, excellent dynamic performance, multiple encoder interfaces, flexible networking options, integrated STO safety, and reliable operation for demanding industrial automation and motion control applications.
