Technical Specifications
| Parameter Category | Details |
|---|---|
| Model Number | KJ3004X1-EA1 |
| Input Power | 32 VDC @ 500 mA |
| Operating Temperature | -40°C to +70°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Vibration Resistance | 2–13.2 Hz, 1 mm peak-to-peak; 13.2–150 Hz, 0.7 g |
| Shock Resistance | 10 g half-sine wave for 11 ms |
| Air Contaminant Class | ISA-S71.04-1985 Class G3 |
| Explosion Protection | II 3G Ex ec IIC Gc and others |
| Installation Note | Must be inserted/removed with power off |
| Dimensions | 100 x 60 x 30 mm |
| Weight | 0.05 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: Can the KJ3004X1-EA1 operate in high temperature environments?
A1: Yes, it operates in a wide temperature range from -40°C to +70°C, suitable for industrial use.
Q2: Is hot-swapping supported for this terminal block?
A2: No, the module must be removed or inserted only when the system is powered off.
Q3: Does the KJ3004X1-EA1 require periodic calibration?
A3: No calibration is required during operation. The unit is factory-calibrated.
Q4: Is any maintenance needed during normal operation?
A4: No. There are no user-serviceable parts inside; disassembly is not recommended.
Q5: What certifications does the module carry for hazardous areas?
A5: It holds certifications such as ATEX, IECEx, and FM, making it suitable for Zone 2 applications.
Q6: What is the standard for airborne contaminants?
A6: It complies with ISA-S71.04-1985 Class G3, allowing use in environments with corrosive elements.
Q7: How is the vibration resistance of the unit?
A7: It withstands up to 0.7 g (13.2–150 Hz) and 1 mm peak-to-peak (2–13.2 Hz) vibration.
Q8: What are the physical dimensions and weight of the unit?
A8: The dimensions are 100 x 60 x 30 mm, and it weighs 0.05 kg, making it compact and easy to install.
