Technical Specifications
| Item | Specification |
|---|---|
| Model | Emerson KJ3203X1-BA1 VE4001S2T2B4 12P3270X022 |
| Product Type | Dry Contact Digital Input Module |
| Module Function | Detects dry contact closures in field circuits |
| Number of Channels | 16 isolated input channels |
| Input Type | Dry contact (voltage-free) |
| Input Voltage Range | 18–32 V DC (nominal 24 V DC) |
| Input Current | ≤ 5 mA per channel |
| Input Isolation | Optical and galvanic isolation per channel |
| Response Time | ≤ 10 ms |
| Diagnostic Features | Channel fault detection and status LEDs |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Mounting | DIN rail or DeltaV system rack |
| Power Supply | Provided through system backplane |
| LED Indicators | Channel and power status indicators |
| Dimensions | 120 x 45 x 130 mm |
| Weight | 0.132 kg |
| Certifications | CE, FM, ATEX, IECEx |
FAQ
FAQ
Q1: What is the function of the KJ3203X1-BA1 module?
A1: It is a 16-channel dry contact input module used to detect contact open/close status in control systems.
Q2: What type of signals does this module accept?
A2: It accepts dry contact (voltage-free) inputs typically from switches, relays, or push buttons.
Q3: How many input channels does it have?
A3: The module provides 16 isolated input channels.
Q4: What is the typical input voltage for the module?
A4: It operates with 24 V DC nominal input voltage, ranging from 18 V to 32 V DC.
Q5: What is the response time of the inputs?
A5: The response time is ≤ 10 ms for each channel.
Q6: Does it provide channel diagnostics?
A6: Yes, it includes LED indicators for each channel to show operational and fault status.
Q7: What are the dimensions and weight of the module?
A7: Dimensions are 120 x 45 x 130 mm, and weight is approximately 0.132 kg.
Q8: What certifications does this module comply with?
A8: It meets CE, FM, ATEX, and IECEx safety and performance standards.
