Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | KJ3242X1-BA1 |
| Product Type | Fieldbus H1 Card |
| Power (Local Bus) | 12 VDC @ 300 mA |
| Power (Fieldbus) | 9–32 VDC @ 12 mA/port |
| Operating Temperature | -40°C to +70°C |
| Shock Resistance | 10g, 11 ms ½ sinewave |
| Vibration Resistance | 2–13.2Hz, 1mm peak-to-peak; 13.2–150Hz, 0.7g |
| Relative Humidity | 5%–95%, non-condensing |
| Air Contaminants | ISA-S71.04–1985 Class G3 |
| Protection Rating | IP20 |
| Terminal Block Key | D6 |
| Certifications | ATEX, IECEx, FM, Nemko, etc. |
| Dimensions | 107 x 41 x 105 mm |
| Weight | 0.181 kg |
FAQ
FAQ
Q1: How many Fieldbus H1 channels does the KJ3242X1-BA1 support?
A1: It supports two H1 channels, each requiring separate power.
Q2: Can the module be inserted or removed under power?
A2: No, unless the area is known to be non-hazardous, and only one unit should be handled at a time.
Q3: Is the module certified for use in Zone 2 hazardous areas?
A3: Yes, it carries certifications such as ATEX II 3G Ex nA IIC Gc for Zone 2 use.
Q4: Does the module require calibration during installation?
A4: No calibration is needed; it is factory calibrated and maintenance-free.
Q5: How is incorrect terminal block insertion avoided?
A5: It uses a rotary keying system that ensures compatibility between the card and its terminal block.
Q6: What level of air contamination can the module withstand?
A6: It meets ISA-S71.04–1985 Class G3 requirements.
Q7: What is the protection rating of the module?
A7: The protection class is IP20, suitable for use inside control cabinets.
Q8: Is hot swapping supported by this module?
A8: Hot swapping is not supported. Power must be turned off before handling the module.
