Technical Specifications
| Parameter | Description |
|---|---|
| Input Power Rating | 35 VDC @ 500 mA |
| Operating Temperature | -40°C to +70°C |
| Vibration Resistance | 1 mm peak-to-peak (2–13.2 Hz), 0.7 g (13.2–150 Hz) |
| Shock Resistance | 10 g half-sine wave for 11 ms |
| Relative Humidity | 5% to 95% non-condensing |
| Airborne Contaminants | ISA-S71.04-1985 Class G3 |
| Intrinsic Safety Rating | II 3G Ex ec IIC Gc |
| Certifications | FM18ATEX0076U, IECEx FMG 18.0030U, etc. |
| Application Environment | Hazardous Zone 2, power-off insertion only |
| Maintenance | No user-serviceable parts, calibration-free |
| Dimensions | 85 x 56 x 35 mm |
| Weight | 0.07 kg |
FAQ
FAQ
Q1: In what environments can the terminal block be used?
A1: It operates in ambient temperatures from -40°C to +70°C and is rated for Class G3 airborne contaminants.
Q2: Is hot-swapping supported for KJ3242X1-EA1?
A2: No, the module must be inserted or removed only when power is turned off.
Q3: Does the module require periodic calibration?
A3: No, it is designed to be calibration-free.
Q4: Does the module have explosion-proof certification?
A4: Yes, it is certified with II 3G Ex ec IIC Gc and other relevant standards.
Q5: Can it operate in high humidity environments?
A5: Yes, it supports 5% to 95% relative humidity (non-condensing).
Q6: What are its vibration tolerance levels?
A6: It handles 1 mm peak-to-peak at 2–13.2 Hz and 0.7 g at 13.2–150 Hz.
Q7: Can users perform internal maintenance?
A7: No, the module contains no user-serviceable parts and should not be disassembled.
Q8: Where is this module typically installed?
A8: It is typically used in DeltaV™ S-Series or CHARMs systems in Zone 2 hazardous areas.
