Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | KL3022X1-BA1 |
| Analog Output Type | 4–20 mA with HART support |
| CHARM Bus Power | +6.3 VDC @ 32 mA |
| Field Circuit Power | +24 VDC @ 30 mA |
| Ambient Temperature | -40 °C to +70 °C |
| Relative Humidity | 5% to 95%, Non-Condensing |
| Shock Rating | 10 g, half-sine wave, 11 ms duration |
| Vibration Rating | 1 mm Peak-to-Peak (2–13.2 Hz), 0.7g (13.2–150 Hz) |
| Airborne Contaminants | ISA-S71.04-1985 Class G3 |
| Terminal Block Key | Position 4A |
| Hazardous Approvals | ATEX, IECEx, FM, UKEX (Zone 2) |
| Dimensions (W x H x D) | 110 x 100 x 30 mm |
| Weight | 0.05 kg |
FAQ
FAQ
Q1: What type of analog output does the KL3022X1-BA1 support?
A1: It supports 4–20 mA output with HART communication protocol.
Q2: Can the module be hot-swapped?
A2: No, the module must not be inserted or removed while powered unless the area is confirmed to be non-hazardous.
Q3: What are the environmental limits for operation?
A3: The module operates from -40 °C to +70 °C and supports Class G3 airborne contaminants.
Q4: Is calibration required during installation?
A4: No calibration is required; the module is maintenance-free.
Q5: What certifications does this module carry?
A5: It is certified for ATEX, IECEx, FM, and UKEX for use in Zone 2 hazardous areas.
Q6: How is compatibility with the terminal block ensured?
A6: A keying system automatically aligns the CHARM with its terminal block upon initial installation.
Q7: What are the power requirements of the module?
A7: It requires +6.3 VDC at 32 mA for the CHARM bus and +24 VDC at 30 mA for the field circuit.
Q8: What shock and vibration standards does the module meet?
A8: It withstands 10 g shock (11 ms half-sine) and vibration of 1 mm peak-to-peak (2–13.2 Hz), 0.7g (13.2–150 Hz).
Tags
