Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | SE4001S2T1B3 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Discrete Input Module with High-Density 16-Channel Terminal Block |
| Application | Digital Signal Acquisition and Monitoring |
| Input Channels | 16 Channels |
| Input Voltage | 24 VDC (Nominal) |
| Input Current | Up to 10 mA per Channel |
| Isolation Voltage | 500 VDC Between Channels and Ground |
| Response Time | Less Than 5 ms |
| Wiring Size | 16 AWG to 20 AWG |
| Power Consumption | Less Than 2.5 W |
| MTBF | Greater Than 100,000 Hours |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Terminal Block Type | High-Density 16-Channel Terminal Block |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | Approximately 150 mm × 120 mm × 30 mm |
| Weight | Approximately 0.35 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Emerson SE4001S2T1B3 used for?
The SE4001S2T1B3 is a discrete input module for monitoring digital signals from field devices such as switches, relays, and status contacts within a DeltaV control system.
Q2: How many input channels does the module have?
This module has 16 discrete input channels, allowing connection of a higher number of field devices compared to standard 8-channel modules.
Q3: What is the input voltage for the SE4001S2T1B3?
The module operates at a nominal 24 VDC, compatible with standard industrial digital inputs.
Q4: What are the physical dimensions of the SE4001S2T1B3?
The module measures approximately 150 mm × 120 mm × 30 mm.
Q5: How much does the SE4001S2T1B3 weigh?
It weighs approximately 0.35 kg, suitable for installation on S-Series carriers.
Q6: Can the SE4001S2T1B3 operate in harsh industrial environments?
Yes, it operates within a temperature range of -20°C to +70°C and supports relative humidity from 5% to 95% non-condensing.
Q7: Does the SE4001S2T1B3 provide electrical isolation?
Yes, the module provides 500 VDC isolation between channels and ground to protect the system from electrical noise and transient disturbances.
Q8: Does the SE4001S2T1B3 require calibration or maintenance?
No routine calibration is required. Periodic inspection of wiring and terminal connections is sufficient to ensure reliable operation.
