Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | SE4001S3T2B2 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Discrete Output Module with Fused 8-Channel Terminal Block (Type 3) |
| Application | Digital Actuation and Control with Circuit Protection |
| Output Channels | 8 Channels |
| Output Voltage | 24 VDC Nominal |
| Output Current | Up to 500 mA per Channel |
| Load Type | Resistive or Inductive Loads |
| Isolation Voltage | 500 VDC Between Channels and Ground |
| Response Time | < 5 ms |
| Wiring Size | 16 AWG to 20 AWG |
| Power Consumption | < 3 W |
| MTBF | > 100,000 Hours |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Terminal Block Type | Fused 8-Channel Output Terminal Block |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | ~100 mm × 120 mm × 30 mm |
| Weight | ~0.28 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Emerson SE4001S3T2B2 used for?
The SE4001S3T2B2 controls digital field devices and provides overcurrent protection via fused output channels.
Q2: How many output channels does it have?
It has 8 discrete output channels.
Q3: What is the output voltage and current?
Each channel provides 24 VDC at up to 500 mA.
Q4: What types of loads can it drive?
It can drive resistive or inductive loads, including relays, solenoids, and indicator lamps.
Q5: What are the module’s dimensions?
The module measures approximately 100 mm × 120 mm × 30 mm.
Q6: How much does the module weigh?
The module weighs approximately 0.28 kg.
Q7: Can it operate in harsh industrial environments?
Yes, it supports -20°C to +70°C and 5%–95% non-condensing humidity.
Q8: Does it require calibration or maintenance?
No calibration is required. Periodic inspection of wiring, terminals, and fuses is sufficient for reliable operation.
