Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | SE4001S5T2B4 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Discrete Output Module with High-Density 32-Channel Terminal Block (Type 5) |
| Application | Digital Actuation and Control for Multiple Field Devices |
| Output Channels | 32 Channels |
| Output Voltage | 24 VDC Nominal |
| Output Current | Up to 500 mA per Channel |
| Load Type | Resistive or Inductive Loads |
| Isolation Voltage | 500 VDC Between Channels and Ground |
| Response Time | Less than 5 ms |
| Wiring Size | 16 AWG to 22 AWG |
| Power Consumption | Less than 8 W |
| MTBF | Greater than 100,000 Hours |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Terminal Block Type | High-Density 32-Channel Output Terminal Block |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | Approximately 300 mm × 120 mm × 30 mm |
| Weight | Approximately 0.80 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Emerson SE4001S5T2B4 used for?
It is used to control up to 32 digital field devices, such as relays, solenoids, and indicators, in a DeltaV distributed control system.
Q2: How many output channels does the module support?
The module provides 32 discrete output channels, enabling high-density actuation control.
Q3: What is the output voltage and current?
The module outputs 24 VDC at up to 500 mA per channel.
Q4: What types of loads can it drive?
It can drive resistive and inductive loads, including relays, solenoids, and small indicator lamps.
Q5: What are the dimensions of the module?
The module measures approximately 300 mm × 120 mm × 30 mm.
Q6: How much does the SE4001S5T2B4 weigh?
The module weighs approximately 0.80 kg.
Q7: Can it operate in harsh industrial environments?
Yes, it is rated for -20°C to +70°C and 5%–95% non-condensing relative humidity.
Q8: Does the module require calibration or routine maintenance?
No calibration is required. Regular inspection of wiring, terminals, and load connections is sufficient to ensure reliable operation.
