Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | SE4001S5T2B5 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Discrete Output Module with 32-Channel Mass Termination Block |
| Application | High-Density Digital Actuation and Control |
| Output Channels | 32 Channels |
| Output Voltage | 24 VDC Nominal |
| Output Current | Up to 500 mA per Channel |
| Load Type | Resistive or Inductive Loads |
| Isolation Voltage | 500 VDC Between Channels and Ground |
| Response Time | < 5 ms |
| Wiring Interface | 40-Pin Mass Termination Block |
| Wiring Size | 16 AWG to 22 AWG |
| Power Consumption | < 8 W |
| MTBF | > 100,000 hours |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Mounting Type | DeltaV S-Series Carrier |
| Dimensions (L × W × H) | ~300 mm × 120 mm × 30 mm |
| Weight | ~0.85 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Emerson SE4001S5T2B5 used for?
The SE4001S5T2B5 is used to control up to 32 digital output devices such as relays, solenoids, and indicator lights in DeltaV control systems.
Q2: How many output channels does it have?
It provides 32 discrete output channels.
Q3: What is the output voltage and current rating?
Each channel outputs 24 VDC with a maximum of 500 mA per channel.
Q4: What type of wiring interface does it use?
It uses a 40-pin mass termination block, allowing high-density and organized field wiring.
Q5: What are the dimensions of the module?
The module measures approximately 300 mm × 120 mm × 30 mm.
Q6: How much does SE4001S5T2B5 weigh?
It weighs approximately 0.85 kg.
Q7: Can it operate in harsh environments?
Yes, it operates between -20°C and +70°C, with up to 95% non-condensing humidity.
Q8: Does it require calibration or maintenance?
No calibration is required. Routine inspection of wiring and termination connections is sufficient for reliable operation.
