Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | SE4002S1T1B1 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Discrete Output Module (8-Channel) |
| Application | Digital Actuation and Control |
| Output Channels | 8 Channels |
| Output Voltage | 24 VDC Nominal |
| Output Current | Up to 0.5 A per Channel |
| Output Type | High-side / isolated discrete output |
| Isolation Voltage | 500 VDC Channel-to-Ground |
| Response Time | < 5 ms |
| Wiring Interface | Standard S-Series Terminal Block (KJ4006X1-BB1 compatible) |
| Wiring Size | 16–22 AWG |
| Power Consumption | < 3 W |
| MTBF | > 100,000 hours |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Mounting Type | DeltaV S-Series Carrier |
| Dimensions (L × W × H) | ~100 mm × 120 mm × 30 mm |
| Weight | ~0.25 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Emerson SE4002S1T1B1 used for?
The SE4002S1T1B1 is used to switch and control field devices like solenoids, relays, and lamps from a DeltaV control system.
Q2: How many output channels does it provide?
It provides 8 discrete output channels.
Q3: What is the output voltage and current rating?
Each channel outputs 24 VDC up to 0.5 A.
Q4: What type of output is it?
It is a high-side isolated discrete output module designed for industrial loads.
Q5: What is the physical size of the module?
It is approximately 100 mm × 120 mm × 30 mm.
Q6: What is the weight of SE4002S1T1B1?
The module weighs approximately 0.25 kg.
Q7: Does it support harsh environments?
Yes, it operates from -20°C to +70°C with up to 95% non-condensing humidity.
Q8: Does it require calibration or maintenance?
No calibration is required. Only routine inspection of wiring and terminal connections is needed.
