Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | SE4002S1T2B3 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Discrete Output Module with High-Density 16-Channel Terminal Block |
| Application | Digital Actuation and Control |
| Output Channels | 16 Channels |
| Output Voltage | 24 VDC Nominal |
| Output Current | Up to 0.5 A per Channel |
| Load Type | Resistive or Inductive Loads |
| Isolation Voltage | 500 VDC Between Channels and Ground |
| Response Time | < 5 ms |
| Wiring Size | 16–22 AWG |
| Power Consumption | < 5 W |
| MTBF | > 100,000 Hours |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Terminal Block Type | High-Density 16-Channel Output Terminal Block |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | ~150 mm × 120 mm × 30 mm |
| Weight | ~0.40 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Emerson SE4002S1T2B3 used for?
It is used to control multiple digital field devices such as relays, solenoids, and indicator lamps from a DeltaV system.
Q2: How many output channels does it have?
The module provides 16 discrete output channels.
Q3: What is the output voltage and current rating?
Each channel outputs 24 VDC at up to 0.5 A.
Q4: What types of loads can it drive?
It can drive both resistive and inductive loads, including industrial actuators and relays.
Q5: What are the physical dimensions?
The module measures approximately 150 mm × 120 mm × 30 mm.
Q6: What is the weight of the module?
It weighs approximately 0.40 kg.
Q7: Can it operate in harsh industrial environments?
Yes, it operates between -20°C and +70°C with up to 95% non-condensing humidity.
Q8: Does it require calibration or maintenance?
No calibration is required. Routine inspection of wiring and terminal connections is sufficient for reliable operation.
