Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | SE4033S2B11 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Discrete Input Plus Module Assembly |
| Application | High-Density Digital Signal Monitoring |
| Input Channels | 32 Channels |
| Input Voltage | 24 VDC Nominal |
| Input Type | Dry Contact and Voltage Input |
| Module Configuration | DI Plus Card with Mass Termination Assembly |
| Terminal Block Type | 40-Pin DI Mass I/O Terminal Block |
| Mass Connection Boards | 4 × 8-Channel DI Mass Connection Boards |
| Signal Isolation | Channel-to-System Isolation |
| Response Time | < 5 ms |
| Wiring Method | Mass Termination Interface |
| Communication Interface | DeltaV S-Series Carrier |
| Hot-Swap Capability | Supported |
| Power Consumption | < 8 W |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | Approximately 300 mm × 120 mm × 35 mm |
| Weight | Approximately 0.95 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Emerson SE4033S2B11 used for?
The SE4033S2B11 is used to monitor digital field signals and transmit status information from field devices to the DeltaV control system. Typical applications include monitoring switches, relay contacts, motor status signals, and proximity sensors.
Q2: How many input channels does the module provide?
The assembly provides 32 discrete input channels, making it suitable for high-density digital monitoring applications.
Q3: What type of signals can be connected to the module?
The module accepts 24 VDC discrete signals, including dry-contact inputs and voltage-based digital signals commonly found in industrial control systems.
Q4: What terminal block is included with the SE4033S2B11?
The assembly includes a 40-pin DI Mass I/O Terminal Block along with four 8-channel DI Mass Connection Boards for simplified wiring and maintenance.
Q5: What are the dimensions of the SE4033S2B11?
The overall assembly measures approximately 300 mm × 120 mm × 35 mm.
Q6: How much does the SE4033S2B11 weigh?
The assembly weighs approximately 0.95 kg.
Q7: Can the module operate in demanding industrial environments?
Yes. It is designed for industrial applications and supports operating temperatures from -40°C to +70°C with 5% to 95% non-condensing humidity.
Q8: Does the SE4033S2B11 require routine calibration?
No calibration is normally required. Recommended maintenance includes periodic inspection of field wiring, terminal connections, and input signal status to ensure reliable operation.
