Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | SE4035S2B5 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Analog Output Plus Module Assembly |
| Application | High-Density Analog Signal Output and Process Control |
| Output Channels | 16 Channels |
| Output Signal Range | 4–20 mA |
| HART Communication | Supported on All Channels |
| Output Resolution | 16-bit Typical |
| Accuracy | ±0.25% of Full Scale |
| Supported Devices | Control Valves, Valve Positioners, VFDs, and Analog Actuators |
| Module Configuration | AO Plus Card with Mass Termination Assembly |
| Terminal Block Type | 48-Pin AO Mass I/O Terminal Block |
| Mass Connection Boards | 2 × 8-Channel AO Mass Connection Boards |
| Isolation | Channel-to-System Isolation |
| Wiring Method | Mass Termination Interface |
| Hot-Swap Capability | Supported |
| Power Consumption | < 10 W |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | Approximately 300 mm × 120 mm × 35 mm |
| Weight | Approximately 1.00 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Emerson SE4035S2B5 used for?
The SE4035S2B5 is used to transmit analog control signals from a DeltaV controller to field devices such as control valves, valve positioners, actuators, and variable frequency drives.
Q2: How many output channels does the module provide?
The assembly provides 16 analog output channels, allowing multiple process devices to be controlled simultaneously.
Q3: Does the SE4035S2B5 support HART communication?
Yes. HART communication is supported on all output channels, enabling device diagnostics, configuration, and status monitoring.
Q4: What type of output signal does the module provide?
The module provides 4–20 mA analog current outputs, which are widely used in industrial process control applications.
Q5: What are the dimensions of the SE4035S2B5?
The assembly measures approximately 300 mm × 120 mm × 35 mm.
Q6: How much does the SE4035S2B5 weigh?
The approximate weight is 1.00 kg.
Q7: What is the advantage of the mass termination design?
The 48-pin mass termination interface reduces installation time, simplifies cable management, improves wiring consistency, and supports high-density I/O installations.
Q8: Does the SE4035S2B5 require routine calibration?
The module generally does not require routine calibration. Periodic verification of output signal accuracy, field wiring integrity, and HART communication status is recommended as part of preventive maintenance procedures.
