Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | SE4085S2B5 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Redundant Analog Output Plus Module Assembly |
| Application | Critical Process Control and High-Availability Analog Output |
| Module Configuration | 2 × AO Plus Cards (Redundant) |
| Output Channels | 16 Channels |
| Output Signal Range | 4–20 mA |
| HART Communication | Supported on All Channels |
| Output Resolution | 16-bit Typical |
| Accuracy | ±0.25% of Full Scale |
| Supported Devices | Control Valves, Positioners, Variable Frequency Drives, and Analog Actuators |
| Redundancy | Full Hardware Redundancy |
| Terminal Block Type | Redundant 48-Pin AO Mass I/O Terminal Block |
| Mass Connection Board | Included 16-Channel AO Mass Connection Board |
| Isolation | Channel-to-System Isolation |
| Wiring Method | Mass Termination Interface |
| Hot-Swap Capability | Supported |
| Power Consumption | < 15 W |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | Approximately 300 mm × 120 mm × 35 mm |
| Weight | Approximately 1.30 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Emerson SE4085S2B5 used for?
The SE4085S2B5 is used to provide highly reliable analog output signals to field devices in critical process automation applications, helping maintain continuous plant operation even if one output card fails.
Q2: How many output channels does the module provide?
The assembly provides 16 analog output channels capable of transmitting 4–20 mA control signals.
Q3: Does the SE4085S2B5 support HART communication?
Yes. All output channels support HART communication, allowing advanced diagnostics, configuration, and device monitoring.
Q4: What is the benefit of the redundant architecture?
The redundant design uses two AO Plus cards operating together, increasing system availability and reducing the risk of process interruptions caused by hardware failures.
Q5: What are the dimensions of the SE4085S2B5?
The assembly measures approximately 300 mm × 120 mm × 35 mm.
Q6: How much does the SE4085S2B5 weigh?
The approximate weight is 1.30 kg.
Q7: What type of field devices can be connected to this module?
The module is designed for devices such as control valves, valve positioners, actuators, variable-frequency drives, and other 4–20 mA analog instruments.
Q8: Does the SE4085S2B5 require routine calibration?
Routine calibration is generally not required. Regular verification of output accuracy, field wiring integrity, redundancy status, and HART communication is recommended as part of preventive maintenance procedures.
