Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | VE4001S2 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Discrete Input Module Assembly |
| Application | Digital Signal Monitoring and Status Acquisition |
| Input Channels | 8 Channels |
| Input Voltage | 24 VDC Nominal |
| Input Type | Dry Contact or Voltage Input |
| Signal Type | Discrete / Digital Input |
| Response Time | < 5 ms |
| Isolation | Channel-to-System Isolation |
| Terminal Block Compatibility | DeltaV S-Series Traditional I/O Terminal Blocks |
| Communication Interface | DeltaV LocalBus |
| Hot-Swap Capability | Supported |
| Power Consumption | Typical 5 W, Maximum 7 W |
| Fuse Protection | 3.0 A Non-Replaceable Fuse |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | Approximately 263 mm × 58 mm × 28 mm |
| Weight | Approximately 0.20 kg |
FAQ
FAQ
Q1: What is the Emerson VE4001S2 used for?
The VE4001S2 is used to acquire digital input signals from field devices and make that information available to the DeltaV control system for monitoring and control functions.
Q2: How many input channels does the module support?
The module provides 8 discrete input channels, allowing multiple field devices to be monitored simultaneously.
Q3: What type of signals can be connected to the VE4001S2?
It accepts 24 VDC discrete signals, including dry-contact inputs and voltage-based digital status signals from industrial field devices.
Q4: Does the module support hot-swapping?
Yes. The module can be replaced while the DeltaV system remains operational, helping minimize downtime during maintenance activities.
Q5: What are the dimensions of the VE4001S2?
The module dimensions are approximately 263 mm × 58 mm × 28 mm.
Q6: How much does the VE4001S2 weigh?
The module weighs approximately 0.20 kg.
Q7: What field devices are commonly connected to this module?
Typical devices include limit switches, pushbuttons, selector switches, relay contacts, proximity sensors, and motor status contacts.
Q8: Does the VE4001S2 require routine calibration?
No routine calibration is required. Recommended maintenance consists of periodically checking wiring integrity, terminal connections, and input signal status to ensure reliable operation.
