Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | VE4002S1 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Discrete Output Module |
| Application | ON/OFF Control of Field Devices |
| Output Channels | 8 Channels |
| Output Type | Sourcing 24 VDC Discrete Output |
| Maximum Load | 0.5 A per Channel |
| Module Configuration | VO Plus Card with Mass Termination Assembly |
| Terminal Block Type | 8-Channel DO Mass I/O Terminal Block |
| Isolation | Channel-to-System Isolation |
| Response Time | < 5 ms |
| Hot-Swap Capability | Supported |
| Communication Interface | DeltaV LocalBus |
| Power Consumption | Typical 5 W, Maximum 7 W |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | Approximately 263 mm × 58 mm × 28 mm |
| Weight | Approximately 0.22 kg |
| Country of Origin | Malaysia / United Kingdom (varies by revision) |
| Typical Applications | Solenoids, Relays, Indicator Lamps, Motor Starters |
FAQ
FAQ
Q1: What is the Emerson VE4002S1 used for?
The VE4002S1 is used to control discrete ON/OFF field devices such as solenoids, relays, motor starters, and indicator lamps in a DeltaV control system.
Q2: How many output channels does the module provide?
The module provides 8 discrete output channels.
Q3: What type of output does the VE4002S1 provide?
It provides 24 VDC sourcing discrete outputs with a maximum load of 0.5 A per channel.
Q4: Can the module be replaced while the system is running?
Yes. The VE4002S1 supports hot swapping, allowing replacement or servicing without shutting down the DeltaV system.
Q5: What are the dimensions of the VE4002S1?
The module measures approximately 263 mm × 58 mm × 28 mm.
Q6: How much does the VE4002S1 weigh?
The weight is approximately 0.22 kg.
Q7: What types of devices can be connected to this module?
Typical devices include solenoids, relays, indicator lamps, motor starters, and other 24 VDC ON/OFF actuators.
Q8: Does the VE4002S1 require routine calibration?
No routine calibration is required. Recommended maintenance includes periodic verification of output signals, wiring integrity, and module diagnostics to ensure reliable operation.
