Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | VE4002S2B2 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Discrete Output Module with Fused 8-Channel Terminal Block |
| Application | Digital ON/OFF Control for Field Devices |
| Output Channels | 8 Channels |
| Output Voltage | 24 VDC Nominal |
| Output Type | Sourcing (High-Side) Discrete Output |
| Output Current | Up to 0.5 A per Channel |
| Load Type | Solenoids, Relays, Motor Starters, Indicator Lamps |
| Terminal Block Type | 8-Channel Fused DO Mass I/O Terminal Block |
| Isolation | Channel-to-System Isolation |
| Response Time | < 5 ms |
| Protection | Individual Channel Fusing |
| Communication Interface | DeltaV LocalBus |
| Hot-Swap Capability | Supported |
| Power Consumption | < 7 W (typical) |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | ~263 mm × 58 mm × 28 mm |
| Weight | ~0.24 kg |
| Country of Origin | United States / Malaysia (varies by revision) |
FAQ
FAQ
Q1: What is the Emerson VE4002S2B2 used for?
It is used to control digital field devices such as solenoids, relays, motor starters, and indicator lamps in DeltaV control systems.
Q2: How many output channels does it provide?
The module provides 8 discrete output channels.
Q3: What is the output voltage and current rating?
Each channel provides 24 VDC output with up to 0.5 A per channel.
Q4: What is the benefit of the “B2” version?
The B2 version includes fused outputs, providing per-channel protection against overloads and short circuits.
Q5: What are the physical dimensions of VE4002S2B2?
The module measures approximately 263 mm × 58 mm × 28 mm.
Q6: What is the weight of the module?
The approximate weight is 0.24 kg.
Q7: Can the module operate in harsh environments?
Yes, it is designed for industrial use with operating temperatures from -40°C to +70°C and up to 95% non-condensing humidity.
Q8: Does the VE4002S2B2 require calibration or maintenance?
No calibration is required. Routine maintenance involves checking wiring integrity, fuse condition, and module diagnostics.
