Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | VE4003S6B1 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | RTD / Resistance Temperature Input Module |
| Application | Temperature Measurement and Process Monitoring |
| Input Channels | 8 Channels |
| Input Type | RTD (Pt100, Pt1000) / Resistance Input |
| Measurement Type | Temperature / Resistance |
| Resolution | 16-bit |
| Accuracy | High-precision RTD measurement (system dependent) |
| Wiring Support | 2-wire, 3-wire, and 4-wire RTD configurations |
| Excitation Current | Low-level precision excitation (channel controlled) |
| Isolation | Channel-to-System Isolation |
| Filtering | Digital filtering for noise reduction |
| Response Time | Configurable (typically < 1 s) |
| Terminal Block Type | RTD/Resistance Terminal Block |
| Communication Interface | DeltaV LocalBus |
| Hot-Swap Capability | Supported |
| Power Consumption | < 5 W |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | ~263 mm × 58 mm × 28 mm |
| Weight | ~0.40 kg |
| Country of Origin | United States |
| Typical Applications | Temperature loops, heat exchangers, reactors, pipelines |
FAQ
FAQ
Q1: What is the Emerson VE4003S6B1 used for?
The VE4003S6B1 is used to measure temperature using RTD sensors and convert resistance signals into process data for the DeltaV control system.
Q2: How many input channels does it support?
It provides 8 RTD input channels.
Q3: What types of RTD sensors are supported?
It supports Pt100, Pt1000, and other resistance-based temperature sensors.
Q4: Does it support different wiring methods?
Yes, it supports 2-wire, 3-wire, and 4-wire RTD configurations for flexible installation.
Q5: What are the module dimensions?
The module measures approximately 263 mm × 58 mm × 28 mm.
Q6: What is the weight of the module?
The approximate weight is 0.40 kg.
Q7: Can the module be replaced while running?
Yes, it supports hot-swapping, allowing replacement without stopping the system.
Q8: Does it require calibration?
The module itself does not require routine calibration; periodic verification of sensor accuracy and loop integrity is recommended.
