Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | VE4003S7B1 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Thermocouple / Temperature Input Module |
| Application | Temperature Measurement and Process Monitoring |
| Input Channels | 8 Channels |
| Input Type | Thermocouple (J, K, T, E, R, S, B, N) |
| Measurement Type | Temperature |
| Input Range | -200°C to +1820°C (depending on thermocouple type) |
| Resolution | 16-bit |
| Accuracy | High-precision (system dependent, ±0.25% typical) |
| Cold Junction Compensation | Built-in for all channels |
| Wiring Support | 2-wire or 3-wire connections |
| Isolation | Channel-to-System Isolation |
| Filtering | Digital filtering for noise reduction |
| Response Time | Configurable (typically < 1 s) |
| Terminal Block Type | Thermocouple Terminal Block |
| Communication Interface | DeltaV LocalBus |
| Hot-Swap Capability | Supported |
| Power Consumption | < 5 W |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | ~263 mm × 58 mm × 28 mm |
| Weight | ~0.42 kg |
| Country of Origin | United States |
| Typical Applications | Reactors, furnaces, heat exchangers, pipelines |
FAQ
FAQ
Q1: What is the Emerson VE4003S7B1 used for?
The VE4003S7B1 is used to measure temperature using thermocouples and transmit accurate temperature data to the DeltaV control system.
Q2: How many input channels does it have?
The module provides 8 thermocouple input channels.
Q3: Which thermocouple types are supported?
It supports J, K, T, E, R, S, B, and N thermocouples.
Q4: Does it include cold junction compensation?
Yes, the module provides built-in cold junction compensation for all channels.
Q5: What are the module dimensions?
The dimensions are approximately 263 mm × 58 mm × 28 mm.
Q6: How much does the VE4003S7B1 weigh?
The module weighs approximately 0.42 kg.
Q7: Can the module be replaced while the system is running?
Yes, it supports hot-swapping, allowing maintenance without shutting down the DeltaV system.
Q8: Does it require calibration?
The module itself does not require routine calibration; periodic verification of thermocouple accuracy and wiring integrity is recommended.
