Technical Specifications
| Item | Specification |
|---|---|
| Model | VE4006P KJ3241X1-BA1 12P2506X042 |
| Brand | Emerson |
| Type | Serial Interface Module |
| Communication Ports | 2 independent RS-232/RS-485 serial ports |
| Supported Protocols | Modbus RTU, ASCII, Pass-through mode |
| Baud Rate Range | 1,200 ~ 115,200 bps |
| Data Bits | 7 or 8 bits |
| Stop Bits | 1 or 2 bits |
| Parity | None, Odd, or Even selectable |
| Isolation Voltage | 250 V AC (channel to system) |
| Power Supply | 24 V DC (±10%) |
| Power Consumption | 3.0 W (typical) |
| Operating Temperature | 0 ~ 60 ℃ |
| Storage Temperature | -40 ~ 85 ℃ |
| Humidity Range | 5% ~ 95% non-condensing |
| Dimensions | 200 ×120 x 60 mm |
| Weight | 0.2 kg |
| Mounting | Installed in DeltaV system backplane slot |
| Applications | Enables serial communication between field intelligent devices and control systems |
FAQ
FAQ
Q1: What is the main function of this module?
It provides RS-232 or RS-485 serial communication interfaces for DeltaV systems.
Q2: What communication protocols are supported?
Supports Modbus RTU, ASCII, and pass-through communication modes.
Q3: How many communication ports does the module have?
It provides two independent configurable serial ports.
Q4: What is the baud rate range?
The baud rate range is 1,200 ~ 115,200 bps, configurable as needed.
Q5: Does the module have isolation protection?
Yes, it features 250 V AC isolation between channel and system.
Q6: What are the power requirements?
Operates at 24 V DC (±10%) with typical power consumption of 3.0 W.
Q7: What is the operating temperature range?
It operates within 0 ~ 60 ℃, suitable for industrial environments.
Q8: What are the typical applications of this module?
Used for connecting field devices, smart instruments, and control systems for data exchange and monitoring.
