Technical Specifications
| Item | Specification |
|---|---|
| Model | VE4012S2B1 KJ3102X1-BA1 12P1863X072 |
| Brand | Emerson |
| Type | Analog Input Module |
| Channels | 8 isolated analog input channels |
| Input Signal Type | 4–20 mA, 0–10 V DC |
| Resolution | 16-bit |
| Accuracy | ±0.1% of full scale |
| Input Impedance | >250 Ω (current input) |
| Update Rate | 100 ms |
| Isolation Voltage | 250 V AC (channel to system) |
| Power Supply | 24 V DC (±10%) |
| Power Consumption | 3.5 W (typical) |
| Operating Temperature | 0 ~ 60 ℃ |
| Storage Temperature | -40 ~ 85 ℃ |
| Humidity | 5% ~ 95% non-condensing |
| Dimensions | 44 × 102 × 108 mm |
| Weight | 0.22 kg |
| Mounting | Installed in DeltaV system backplane slot |
| Applications | Industrial process control, analog signal acquisition, real-time monitoring systems |
FAQ
FAQ
Q1: What is the primary function of this module?
It is used for collecting analog signals from field devices such as pressure, temperature, and flow sensors.
Q2: How many input channels does it provide?
The module offers 8 isolated analog input channels.
Q3: What types of input signals are supported?
Supports 4–20 mA and 0–10 V DC input signals.
Q4: What is the module resolution?
The resolution is 16-bit, enabling high-precision measurements.
Q5: What are the power requirements?
Operates at 24 V DC (±10%) with a typical power consumption of 3.5 W.
Q6: What is the operating temperature range?
The module operates within 0 ~ 60 ℃.
Q7: How is the module installed?
It is installed via a DeltaV system backplane slot for easy integration.
Q8: What are the common applications of this module?
Used in process control, instrumentation data acquisition, and real-time monitoring systems.
