Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | VE4035S2 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Analog Input Module |
| Application | Process Signal Acquisition and Monitoring |
| Input Channels | 8 Channels |
| Input Signal Type | 4–20 mA Current / Voltage Signals |
| Input Resolution | 16-bit |
| Accuracy | ±0.1% of Span (Typical) |
| Input Impedance | 250 Ω (for current input) |
| HART Communication | Supported |
| Isolation | Channel-to-System Isolation |
| Terminal Block Type | 8-Channel AI Mass I/O Terminal Block |
| Response Time | < 10 ms |
| Hot-Swap Capability | Supported |
| Communication Interface | DeltaV LocalBus |
| Power Consumption | < 10 W |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | Approximately 263 mm × 58 mm × 28 mm |
| Weight | Approximately 0.35 kg |
| Country of Origin | United States |
| Typical Applications | Pressure transmitters, flow meters, level sensors, temperature transmitters |
FAQ
FAQ
Q1: What is the Emerson VE4035S2 used for?
The VE4035S2 is used to acquire analog signals (4–20 mA) from field devices and transmit them to the DeltaV control system for process monitoring.
Q2: How many input channels does the module have?
It provides 8 analog input channels.
Q3: Does the module support HART communication?
Yes, all channels support HART communication for device diagnostics and configuration.
Q4: What types of signals can be connected?
It supports 4–20 mA current inputs and voltage inputs, depending on the system configuration.
Q5: What are the module dimensions?
The module measures approximately 263 mm × 58 mm × 28 mm.
Q6: How much does the VE4035S2 weigh?
The module weighs approximately 0.35 kg.
Q7: Can the module be replaced while the system is running?
Yes, it supports hot-swapping, allowing maintenance or replacement without shutting down the DeltaV system.
Q8: Does the VE4035S2 require calibration?
No routine calibration is required. Periodic verification of wiring integrity and signal accuracy is recommended to maintain optimal performance.
