Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | VE4037P |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Power Supply Module |
| Application | Provides Power to S-Series I/O Modules |
| Output Voltage | 24 VDC Nominal |
| Output Current | 5 A Maximum |
| Output Power | 120 W Maximum |
| Input Voltage | 100–240 VAC, 50/60 Hz |
| Efficiency | > 85% Typical |
| Protection Features | Overcurrent, Overvoltage, Short-Circuit Protection |
| Isolation | Input-to-Output Isolation |
| Communication Interface | DeltaV LocalBus Status Monitoring |
| Hot-Swap Capability | Supported |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Mounting Type | DeltaV S-Series Carrier / Rack Installation |
| Dimensions (L × W × H) | Approximately 200 mm × 100 mm × 50 mm |
| Weight | Approximately 1.2 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Emerson VE4037P used for?
The VE4037P is used to provide stable 24 VDC power to DeltaV S-Series I/O modules in process control systems.
Q2: What is the maximum output current of the module?
The maximum output current is 5 A.
Q3: What input voltage does the VE4037P support?
It supports 100–240 VAC at 50/60 Hz.
Q4: Does the module support hot-swapping?
Yes. The VE4037P supports hot-swapping, allowing replacement without shutting down the system.
Q5: What protection features are included?
The module includes overcurrent, overvoltage, and short-circuit protection.
Q6: What are the module dimensions?
The dimensions are approximately 200 mm × 100 mm × 50 mm.
Q7: How much does the VE4037P weigh?
The module weighs approximately 1.2 kg.
Q8: Can it power all S-Series I/O modules?
Yes, the VE4037P is designed to reliably supply 24 VDC power to all DeltaV S-Series I/O modules within its current rating.
