Technical Specifications
| Parameter | PR6423 Eddy Current Sensor | CON041 Signal Converter |
|---|---|---|
| Sensor Tip Diameter | 8 mm | — |
| Linear Measurement Range | 2.0 mm | Dependent on model configuration |
| Initial Air Gap | 0.5 mm | — |
| Incremental Scale Factor | 8 V/mm (±5%) | — |
| Linearity Error | ±0.025 mm (±1 mil) | ≤1.0% for PR6423 Standard |
| Frequency Response | — | 0 to 20,000 Hz |
| Rise Time | — | <15 µs |
| Protection Class | IP66 (sensor) | IP20 |
| Operating Temperature | -35 to +180°C (sensor) | -30 to +100°C |
| Shock Resistance | — | 5g @ 60 Hz @ 25°C |
| Supply Voltage Range | — | -23V to -32V (Output: -4V to -20V) |
| -21V to -32V (Output: -2V to -18V) | ||
| Material | Sensor: Stainless steel, PEEK; Cable: PTFE | Housing: PA 6.6 |
| Mounting | Threaded (M10x1 or 3/8”-24 UNF) | DIN Rail |
| Connection Type | Lemo or open cable end | Screw Terminal (Max 1.5 mm²) |
| Minimum Shaft Diameter | 25 mm | — |
| Weight | 0.10 kg (Sensor with 1m Cable) | 0.06 kg |
| Compliance | CE, ATEX, IEC-Ex, CSA, UL | CE, ATEX, IEC-Ex, CSA, UL |
| Hazardous Area Approval | Intrinsically safe / Non-sparking | Intrinsically safe / Non-sparking |
FAQ
FAQ
Q1: What types of machinery is this sensor suitable for?
A1: The PR6423 sensor is suitable for critical rotating machines such as steam turbines, gas turbines, hydro turbines, compressors, gearboxes, pumps, and fans.
Q2: What is the linear measurement range of the PR6423?
A2: The PR6423 provides a linear measurement range of 2.0 mm with an initial air gap of 0.5 mm.
Q3: Does the CON041 converter support multiple sensor models?
A3: Yes, CON041 is designed to be compatible with PR6422, PR6423, PR6424, PR6425, and PR6426 sensors.
Q4: What is the operating temperature range for the PR6423?
A4: The sensor operates from -35°C to +180°C with a 1-meter cable.
Q5: What is the frequency response range of the CON041?
A5: It offers a frequency response from 0 to 20,000 Hz, suitable for high-speed dynamic measurements.
Q6: Are intrinsic safety certifications available?
A6: Yes, both PR6423 and CON041 carry intrinsic safety and non-sparking approvals such as ATEX, IEC-Ex, and CSA.
Q7: Does PR6423 come with different thread mounting options?
A7: Yes, standard mounting thread options include M10x1 and 3/8”-24 UNF.
Q8: What is the combined weight of the sensor and converter?
A8: The PR6423 sensor weighs approximately 0.10 kg and the CON041 converter weighs about 0.06 kg, totaling around 0.16 kg.
