Technical Specifications
| Parameter | Specification |
|---|---|
| Sensor Model | Epro PR6423/003-010-CN |
| Converter Model | CON021 |
| Sensor Type | Non-contact Eddy Current Displacement Sensor |
| Measurement Range | 2.0 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Scale Factor | 8 V/mm ±5% (203.2 mV/mil) |
| Linearity Error (DSL) | ±0.025 mm (±1 mil) |
| Minimum Shaft Diameter | 25 mm (0.98 in) |
| Target Material | 42CrMo4 (AISI 4140) |
| Sensor Protection Class | IP66 (IEC 60529) |
| Converter Protection Class | IP20 |
| Sensor Temperature Range | -35°C to +180°C |
| Converter Temperature Range | -30°C to +100°C |
| Frequency Range (Converter) | 0 to 20000 Hz |
| Rise Time (Converter) | <15 µs |
| Sensor Material | Tip: PEEK; Case: Stainless Steel; Cable: PTFE; Connector: Nickel-plated brass |
| Converter Material | LMgSi 0.5 F22 |
| Sensor Weight | 0.10 kg (with 1m cable) |
| Converter Weight | ~0.12 kg |
| Sensor Tip Diameter | 8 mm |
| Mounting (Converter) | Panel mount, 4x M5 screws |
| Output Voltage Range | -4V to -20V or -2V to -18V (depending on supply) |
| Certifications | CE, ATEX, IECEx, CSA, UL |
FAQ
FAQ
Q1: What is the primary function of the PR6423 sensor?
A1: It measures dynamic displacement, position, eccentricity, and speed of rotating shafts in turbomachinery.
Q2: What applications is this sensor and converter combination suitable for?
A2: It is designed for steam turbines, gas turbines, hydro turbines, compressors, pumps, and fans.
Q3: What is the linear measurement range of the PR6423 sensor?
A3: The sensor has a linear measurement range of 2.0 mm.
Q4: What is the protection rating of the PR6423 sensor?
A4: The PR6423 sensor is rated IP66, making it dust-tight and protected against strong water jets.
Q5: Is the sensor certified for hazardous areas?
A5: Yes, the sensor is certified under ATEX, IECEx, CSA, and UL standards for intrinsic safety and non-sparking applications.
Q6: Can the CON021 converter be used with other probe models?
A6: Yes, it is compatible with PR6422, PR6423, PR6424, PR6425, and PR6426 sensors.
Q7: What is the output signal range of the converter?
A7: Depending on the supply voltage, the output range is either -4V to -20V or -2V to -18V.
Q8: What is the diameter and weight of the PR6423 sensor tip?
A8: The tip diameter is 8 mm and the sensor (with 1m cable) weighs approximately 0.22 kg.
