Technical Specifications
| Parameter | Value |
|---|---|
| Sensor Type | Eddy Current Displacement Sensor |
| Model | PR6423/00E-030 |
| Tip Diameter | 8 mm |
| Linear Measurement Range | 2 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Incremental Scale Factor (ISF) | 8 V/mm (203.2 mV/mil) ±5% (0–45°C) |
| Deviation from Best Fit Line | ±0.025 mm (±1 mil) (0–45°C) |
| Minimum Shaft Diameter | 25 mm (0.98 in) |
| Target Material | 42CrMo4 (AISI/SAE 4140), others on request |
| Operating Temperature | Sensor: –35 to +180°C; Cable & Connector: –35 to +150°C |
| Material Composition | Tip: PEEK; Case: Stainless Steel; Cable: PTFE; Connector: Nickel-plated brass |
| Protection Class | IP66 (IEC 60529) |
| Certifications | CE, ATEX, IECEx, CSA, UL, RoHS compliant |
| Hazardous Area Approvals | Intrinsic Safety (ia), Non-sparking (nA), T6/T4/T3 classes |
| Dimensions | Case thread: M10x1 or 3/8-24UNF, Cable Ø 2.8 mm, min bend radius 25 mm |
| Weight | 0.1 kg (with 1 m cable) |
FAQ
FAQ
Q1: What are the typical applications for the PR6423/00E-030 sensor?
A1: It is used for shaft displacement monitoring in turbines, compressors, gearboxes, pumps, and fans.
Q2: What is the linear measurement range of this sensor?
A2: The sensor offers a linear range of 2 mm with an initial air gap of 0.5 mm.
Q3: Is it certified for use in hazardous areas?
A3: Yes, it holds ATEX, IECEx, and CSA certifications for intrinsic safety and non-sparking applications.
Q4: What is the operational temperature range?
A4: The sensor operates between –35°C and +180°C; cables and connectors can operate up to +150°C.
Q5: Can it be used on small shaft diameters?
A5: The minimum recommended shaft diameter is 25 mm for accurate measurement.
Q6: Is the sensor environmentally sealed?
A6: Yes, it is rated IP66 for protection against dust and water ingress.
Q7: Are the sensor materials corrosion-resistant?
A7: Yes, the tip is made from PEEK, the case is stainless steel, and the cable is PTFE—all highly durable materials.
Q8: Are different mounting configurations supported?
A8: Yes, both standard and reverse mount versions are available, with customizable cable lengths and armored options.
