Technical Specifications
| Parameter | Specification |
|---|---|
| Tip Diameter | 8 mm |
| Linear Measurement Range | 2 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Incremental Scale Factor (ISF) | 8 V/mm (203.2 mV/mil) ±5% (0–45°C) |
| Deviation from DSL | ±0.025 mm (±1 mil) |
| Minimum Shaft Diameter | 25 mm (0.79″) |
| Target Material | 42CrMo4 (AISI/SAE 4140) or on request |
| Protection Class | IP66 (IEC 60529) |
| Operating Temperature | Sensor (w/ 1m cable): -35°C to +180°C |
| Cable & connector: -35°C to +150°C | |
| Material | Tip: PEEK; Case: Stainless Steel; Cable: PTFE; Connector: Brass |
| Thread Size | M10x1 or 3/8-24UNF |
| Cable Diameter (Standard) | 2.8 mm (min. bend radius 25 mm) |
| Cable Diameter (Armored) | 6.0 mm (min. bend radius 35 mm) |
| Connector | Lemo (Ø11 mm) or open end |
| Weight | Approx. 0.1 kg (100 g) |
| Certifications | CE, ATEX, IECEx, CSA, UL |
| Hazardous Area Approval | Intrinsic Safety (ia), Non-sparking (nA) |
| Temperature Classifications | T6: ≤64°C, T4: ≤114°C, T3: ≤160°C |
FAQ
FAQ
Q1: What applications is this sensor suitable for?
A1: The PR6423 is ideal for monitoring shaft displacement, position, eccentricity, and speed in turbines, compressors, gearboxes, pumps, and fans.
Q2: What is the linear measurement range of the sensor?
A2: It offers a linear measurement range of 2 mm (80 mils).
Q3: What is the protection rating of the PR6423 sensor?
A3: It is rated IP66, making it resistant to dust and water ingress.
Q4: What is the minimum shaft diameter it can measure?
A4: The minimum measurable shaft diameter is 25 mm (0.79″).
Q5: What material is used for the sensor tip?
A5: The sensor tip is made of PEEK (Polyether Ether Ketone), offering high thermal and chemical resistance.
Q6: Does the sensor have hazardous area certifications?
A6: Yes, it complies with ATEX, IECEx, and CSA standards for use in explosive environments.
Q7: Is armored cable available?
A7: Yes, both armored and non-armored cable options are available. The armored version has a 6 mm diameter.
Q8: What is the weight of the sensor?
A8: The sensor with 1 meter of cable weighs approximately 0.1 kg.
