Technical Specifications
| Parameter Category | Details |
|---|---|
| Linear Measurement Range | 2 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Incremental Scale Factor | 8 V/mm (203.2 mV/mil) ±5%, from 0 to 45°C |
| DSL (Linearity Deviation) | ±0.025 mm (±1 mil) from 0 to 45°C |
| Min. Shaft Diameter | 25 mm (0.79 in) |
| Target Material | Standard: 42CrMo4 (AISI/SAE 4140); Others on request |
| Protection Class | IP66 (IEC 60529) |
| Operating Temperature | Sensor with 1m cable: -35 to +180°C; Cable & Connector: -35 to +150°C |
| Material Composition | Tip: PEEK; Case: Stainless Steel; Cable: PTFE; Connector: Nickel-plated Brass |
| Weight | Approx. 0.1 kg (with 1m cable) |
| Sensor Diameter | 8 mm |
| Certifications | CE, ATEX, IECEx, CSA, UL and others (see datasheet) |
| Hazardous Area Ratings | Intrinsically Safe (ia), Non-sparking (nA), Ratings T6/T4/T3 depending on temperature |
FAQ
FAQ
Frequently Asked Questions
Q1: What is the measurement range of this sensor?
A1: The linear measurement range is 2 mm (80 mils).
Q2: What types of equipment is it suitable for?
A2: It’s designed for critical turbomachinery like steam, gas, hydro turbines, compressors, gearboxes, pumps, and fans.
Q3: Can it operate in high-temperature environments?
A3: Yes, the sensor itself can withstand temperatures up to 180°C.
Q4: What is the output signal specification?
A4: It provides a voltage output with a scale factor of 8 V/mm, compatible with Emerson’s signal converters.
Q5: Is it suitable for hazardous area applications?
A5: Yes, it is certified for use in hazardous areas with ATEX, IECEx, and CSA approvals.
Q6: What is the weight and is it easy to install?
A6: The sensor weighs approximately 0.1 kg with a 1-meter cable and is compact and easy to install.
Q7: What is the minimum shaft diameter it can measure?
A7: It can measure shafts with a minimum diameter of 25 mm.
Q8: Is there a radiation-resistant version available?
A8: Yes, a special version (PR6423/xxx-xxx-RAD) is available for radiation environments.
