Technical Specifications
| Item | Specification |
|---|---|
| Model | PR6424/008-030 |
| Product Type | Eddy Current Displacement Sensor |
| Measurement Principle | Non-contact eddy current |
| Sensor Head Diameter | 16 mm |
| Measuring Type | Radial shaft displacement and vibration |
| Output Signal | Analog voltage via compatible driver module |
| Sensitivity | 8 mV/µm typical (with matching driver) |
| Measuring Range | 3 mm |
| Linearity | ≤ ±1% of full scale |
| Resolution | < 1 µm |
| Frequency Response | 0–10 kHz |
| Target Material | Conductive metals (steel standard) |
| Temperature Drift | Low thermal drift design |
| Environmental Protection | Industrial sealed housing |
| Electrical Connection | Connector interface for driver module |
| Shock Resistance | High-shock resistant |
| Vibration Resistance | Suitable for high-speed rotating machinery |
| Housing Material | Stainless steel |
| Installation Method | Threaded mounting |
| Operating Temperature | -35°C to +180°C |
| Storage Temperature | -40°C to +200°C |
| Relative Humidity | 95% max, non-condensing |
| Weight | 0.2 kg |
FAQ
FAQ
Q1: What is the primary application of the PR6424/008-030 sensor?
A1: It measures radial shaft displacement and vibration in rotating machinery without physical contact.
Q2: How accurate is the sensor in detecting small displacements?
A2: It has a resolution below 1 µm, suitable for precise industrial monitoring.
Q3: Can the sensor handle fluctuating temperature conditions?
A3: Yes, the low thermal drift design ensures consistent performance across temperature changes.
Q4: Is the sensor suitable for high-speed equipment?
A4: Yes, it is designed to withstand vibrations and shock from high-speed rotating machinery.
Q5: How is the analog signal obtained?
A5: The sensor requires a compatible driver module to convert measurements into a standard analog voltage.
Q6: Can it measure non-ferrous metals?
A6: Yes, it can measure any conductive metal, though steel is the default calibration target.
Q7: How is the sensor physically mounted?
A7: Threaded mounting ensures secure positioning and accurate alignment with the target shaft.
Q8: Can the sensor monitor both displacement and vibration simultaneously?
A8: Yes, it provides high-resolution readings suitable for simultaneous displacement and vibration monitoring.
