Technical Specifications
| Parameter | Description |
|---|---|
| Model | Epro PR6424/109-101 |
| Type | 16 mm Eddy Current Displacement/Vibration Sensor |
| Probe Diameter | 16 mm |
| Measurement Principle | Non-contact eddy current |
| Measurement Range | Typically 0 … 2.0 mm (depends on driver & extension cable) |
| Sensitivity | Approx. 7.87 mV/μm (with matching driver) |
| Linearity | < 1% FS |
| Operating Temperature | -35°C to +180°C |
| Storage Temperature | -40°C to +200°C |
| Housing Material | Stainless steel |
| Cable Type | Integrated shielded cable |
| Cable Length | 10 m (variant-specific, enhanced thermal type) |
| Mounting Style | Threaded mounting with compatible sleeves |
| Environmental Resistance | Oil-resistant, vibration-resistant |
| Dimensions | Sensor head diameter 16 mm |
| Weight | 0.2 kg |
FAQ
FAQ
Q1: What is the difference between PR6424/109-101 and 109-100?
A1: The 109-101 variant typically includes enhancements in cable insulation or shielding structure, while core measurement performance remains the same.
Q2: Does it require a specific driver such as PR6423?
A2: Yes, matching with a compatible driver is necessary for correct range, linearity, and sensitivity.
Q3: Can the sensor operate continuously in high-temperature areas?
A3: Yes, it supports continuous operation up to +180°C.
Q4: Is the cable customizable?
A4: No, the cable is integrated and non-replaceable.
Q5: Is it fully compatible with the VM600 system?
A5: Yes, the PR6424 series is a standard sensor for VM600 applications.
Q6: Do I need a dedicated mounting sleeve?
A6: Recommended, to maintain gap and linearity performance.
Q7: Can the sensing range be adjusted?
A7: No, it is determined by the driver, not the probe.
Q8: Can it be used for axial displacement monitoring?
A8: Yes, it supports axial, radial vibration, and displacement measurement.
