Technical Specifications
| Parameter | Specification |
|---|---|
| Model | PR6480/031‑000 Eddy Current Probe / Probe Holder |
| Product Type | Eddy current probe holder for mounting proximity sensors |
| Compatible Sensors | Designed to accommodate EPRO eddy current proximity sensors (e.g., PR6422 / PR6423) |
| Application | Permits external mounting and adjustment of eddy current sensors while machine is operating |
| Housing Material | Stainless steel probe holder body with optional connection head (aluminum die‑cast) |
| Protection Class | IP45 standard (connection head); up to IP65 when sealed with adhesive |
| Operating Temperature Range | Typical industrial range aligned with installed sensor specifications |
| Pressure / Differential Pressure | Up to ~2000 hPa when holder and sensor are sealed |
| Mounting Method | Fixed flange‑type probe holder; allows sensor adjustment from outside machine casing |
| Supported Shaft / Probe Length | Adjustable mounting range typically available from ~30 mm to ~450 mm (holder sleeve range; depends on part code and holder variation) |
| Cable & Connector | Depends on mounted sensor; holder permits sealed route for cable |
| Weight | Varies by holder length and accessories (probe only holder is lightweight) |
| Dimensions | Adjustable holder length range approx. 30–450 mm depending on configuration; typical stainless steel sleeve with connection head |
FAQ
FAQ
Q1: What is the PR6480/031‑000 used for?
It is a probe holder that allows installation and adjustment of an eddy current proximity sensor (like PR6422/PR6423) from outside the machine casing.
Q2: Which sensors can be mounted using this holder?
It is designed to work with compact proximity sensors in the EPRO PR6422 and PR6423 series.
Q3: How does the PR6480/031‑000 improve installation?
The holder lets technicians adjust or replace the sensor without opening the machine housing, saving maintenance time.
Q4: What materials is the holder made of?
It uses a stainless steel body with an optional aluminum die‑cast connection head for durability and environmental protection.
Q5: What environmental protection does this holder provide?
Standard IP45 protection is provided; sealing the adapter sleeve with adhesive can achieve up to IP65 against dust and moisture.
Q6: What machine environments is this suitable for?
It is used in critical rotating machinery such as turbines, compressors, pumps, and gearboxes where sensors require external access.
Q7: Does PR6480/031‑000 include the sensor?
No — it is a holder / mounting fixture; a compatible eddy current sensor (e.g., PR6422/PR6423) must be installed into it.
Q8: What size range does the holder support?
The adjustable holder typically spans ≈30 mm to ≈450 mm in length (depending on specific version and mounting option), accommodating different sensor reach and machine geometry.
