Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Foxboro (Schneider Electric / Invensys) |
| Model | FBM205 |
| Product Number | P0914XG |
| Current / Superseding Part Number | RH914XG |
| Product Type | Redundant Analog I/O Interface Module |
| System | Foxboro I/A Series / Standard 200 Series |
| Input Channels | 4 isolated analog input channels |
| Output Channels | 4 isolated analog output channels |
| Input Signal | 0–20 mA DC |
| Output Signal | 0–20 mA DC |
| Channel Isolation | Galvanically isolated between channels and ground |
| Input / Output Range | 0–20.4 mA DC |
| Redundancy | Designed for redundant operation using two FBM205 modules |
| Fieldbus Communication | Redundant 2 Mbps Module Fieldbus |
| Power Supply | 24 VDC (+5%, -10%), redundant input |
| Power Consumption | 10 W maximum per redundant pair |
| Main Function | Provides isolated analog input and output interfaces between field devices and the Foxboro control system |
| Mounting | Standard 200 Series baseplate; DIN rail or 19-inch rack mounting |
| Operating Temperature | -20 to +70°C |
| Relative Humidity | 5–95%, non-condensing |
| Dimensions (L × W × H) | 104 × 45 × 102 mm |
| Dimensions with Mounting Lugs | 104 × 45 × 114 mm |
| Approx. Weight | 0.284 kg |
| Origin | USA |
FAQ
FAQ
Q1: What is Foxboro FBM205 P0914XG?
A: It is a Redundant Analog I/O Interface Module for Foxboro I/A Series and Standard 200 Series control systems.
Q2: How many input and output channels does FBM205 provide?
A: It provides 4 analog input channels and 4 analog output channels, for a total of 8 I/O channels. Both inputs and outputs use 0–20 mA DC signals.
Q3: Are the input and output channels isolated?
A: Yes. Each input and output channel is galvanically isolated from the other channels and from ground.
Q4: How does FBM205 provide redundancy?
A: FBM205 is designed to operate as a redundant pair of two modules. A redundant adapter connects the two adjacent FBM205 modules to the associated termination assembly.
Q5: What type of signals does P0914XG handle?
A: The module handles 0–20 mA DC analog signals, with four input channels and four output channels. The specified channel range is approximately 0–20.4 mA DC.
Q6: How does P0914XG communicate with the control system?
A: It communicates with the associated FCM or FCP through the redundant 2 Mbps Module Fieldbus.
Q7: What are the dimensions and weight of P0914XG?
A: The module measures approximately 104 × 45 × 102 mm (L × W × H), or 104 × 45 × 114 mm including mounting lugs, and weighs approximately 0.284 kg.
Q8: Is P0914XG still the current part number?
A: P0914XG is the earlier part number. RH914XG is the current/superseding part number for the FBM205 redundant 0–20 mA I/O interface module.
